Telecentric lens series, 35mm Full Frame

Telecentric lenses

Telecentric lens series, 35mm Full Frame

  • 38 models
  • from $4,609.00
  • Series LS-TCL-S13

The Telecentric lens series, 35mm Full Frame is a range of 38 telecentric lenses from LumaSpec Vision, from $4,609.00. It comes in 13 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Build a system with this series See all 38 models Series datasheet (PDF)

The series at a glance

Sizes / versions
0.116×, 0.15×, 0.187×, 0.245×, 0.289×, 0.38×, 0.463×, 0.561×, 0.641×, 0.75×, 1×, 2×, 3×
Mount
M58, F-mount
Image circle
30-45 mm
Type
Object-side telecentric
Magnification
0.1-0.3x, 0.3-0.6x, 0.6-1x, 1-2x, 2x +
Working distance
Under 65 mm, 65-110 mm, 110-200 mm, 200 mm +
Sensor format
APS-H / Full frame

All 38 models in the Telecentric lens series, 35mm Full Frame

Link
LS-TCL-01843×4 μm57.8 mmF-mount$4,609.00quoteView
LS-TCL-01853×4 μm57.8 mmM58-mount$4,609.00quoteView
LS-TCL-01863×4 μm57.8 mmM58-mount$4,609.00quoteView
LS-TCL-01872×5 μm57.8 mmF-mount$4,609.00quoteView
LS-TCL-01882×5 μm57.8 mmM58-mount$4,609.00quoteView
LS-TCL-01892×5 μm57.8 mmM58-mount$4,609.00quoteView
LS-TCL-01901×10 μm102.6 mmF-mount$4,609.00quoteView
LS-TCL-01911×10 μm102.6 mmM58-mount$4,609.00quoteView
LS-TCL-01921×10 μm102.6 mmM58-mount$4,609.00quoteView
LS-TCL-01940.75×14 μm125.6 mmM58-mount$4,869.00quoteView
LS-TCL-01950.75×14 μm125.6 mmM58-mount$4,869.00quoteView
LS-TCL-01960.641×16 μm148.6 mmF-mount$5,119.00quoteView
LS-TCL-01970.641×16 μm148.6 mmM58-mount$5,119.00quoteView
LS-TCL-01980.641×16 μm148.6 mmM58-mount$5,119.00quoteView
LS-TCL-01990.561×18 μm170.6 mmF-mount$5,369.00quoteView
LS-TCL-02000.561×18 μm170.6 mmM58-mount$5,369.00quoteView
LS-TCL-02010.561×18 μm170.6 mmM58-mount$5,369.00quoteView
LS-TCL-02020.463×22 μm197.3 mmF-mount$6,119.00quoteView
LS-TCL-02030.463×22 μm197.3 mmM58-mount$6,119.00quoteView
LS-TCL-02040.463×22 μm197.3 mmM58-mount$6,119.00quoteView
LS-TCL-02050.38×27 μm262.3 mmF-mount$6,789.00quoteView
LS-TCL-02060.38×27 μm262.3 mmM58-mount$6,789.00quoteView
LS-TCL-02070.38×27 μm262.3 mmM58-mount$6,789.00quoteView
LS-TCL-02080.289×35 μm331.6 mmF-mount$7,669.00quoteView
LS-TCL-02090.289×35 μm331.6 mmM58-mount$7,669.00quoteView
LS-TCL-02100.289×35 μm331.6 mmM58-mount$7,669.00quoteView
LS-TCL-02110.245×41 μm397.4 mmF-mount$8,919.00quoteView
LS-TCL-02120.245×41 μm397.4 mmM58-mount$8,919.00quoteView
LS-TCL-02130.245×41 μm397.4 mmM58-mount$8,919.00quoteView
LS-TCL-02140.187×54 μm457.5 mmF-mount$13,329.00quoteView
LS-TCL-02150.187×54 μm457.5 mmM58-mount$13,329.00quoteView
LS-TCL-02160.187×54 μm457.5 mmM58-mount$13,329.00quoteView
LS-TCL-02170.15×68 μm542.8 mmF-mount$16,469.00quoteView
LS-TCL-02180.15×68 μm542.8 mmM58-mount$16,469.00quoteView
LS-TCL-02190.15×68 μm542.8 mmM58-mount$16,469.00quoteView
LS-TCL-02200.116×44 μm500 mmF-mount$53,609.00quoteView
LS-TCL-02210.116×44 μm500 mmM58-mount$53,609.00quoteView
LS-TCL-02220.116×44 μm500 mmM58-mount$53,609.00quoteView
