Telecentric lenses
Bi-telecentric lens for 1/2.5" cameras (LS-TCL-S77)
- 26 models
- from $1,619.00
- Series LS-TCL-S77
The Bi-telecentric lens for 1/2.5" cameras (LS-TCL-S77) is a range of 26 telecentric lenses from LumaSpec Vision, from $1,619.00. It comes in 26 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 0.024x, WD 465 mm, 1/2.5", C-Mount, 0.027x, WD 438 mm, 1/2.5", C-Mount, 0.03x, WD 410 mm, 1/2.5", C-Mount, 0.033x, WD 372 mm, 1/2.5", C-mount, 0.038x, WD 330 mm, 1/2.5", C-mount, 0.042x, WD 318 mm, 1/2.5", C-Mount, 0.048x, WD 301 mm, 1/2.5", C-Mount, 0.053x, WD 288 mm, 1/2.5", C-Mount, 0.06x, WD 280 mm, 1/2.5", C-mount, 0.065x, WD 251 mm, 1/2.5", C-Mount, 0.077x, WD 254 mm, 1/2.5", C-Mount, 0.08x, WD 208 mm, 1/2.5", C-mount, 0.09x, WD 229 mm, 1/2.5", C-Mount, 0.1x, WD 178 mm, 1/2.5", C-Mount, 0.112x, WD 159 mm, 1/2.5", C-Mount, 0.113x, WD 187 mm, 1/2.5", C-Mount and 10 more
- Mount
- C-mount
- Image circle
- Up to 8 mm
- Type
- Bi-telecentric
- Magnification
- Under 0.1x, 0.1-0.3x
- Working distance
- 65-110 mm, 110-200 mm, 200 mm +
- Sensor format
- 1/2.5" and smaller
Features
- Matrix design with extremely high imaging quality
- Standard FOV from 26 to 240 mm, covering almost all industrial imaging applications
- Compatible with all C-mount cameras from 1/2.5" to 1.1", and F/M-mount cameras from 4/3" to 59 mm
- More than 168 standard types and hundreds of customised items
- Excellent F-number, high telecentricity, extremely low distortion, very large DoF
- Each lens comes with an imaging quality test report
- Lens mount with conveniently adjustable flange distance (AL)
- Matrix-design with extremely high imaging quality
Typical uses
- Industrial imaging applications (standard FOV 26 to 240 mm)
All 26 models in the Bi-telecentric lens for 1/2.5" cameras (LS-TCL-S77)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-TCL-2568 | 0.277x, WD 72 mm, 1/2.5", C-Mount | 0.277 | 72±2 | $1,619.00 | View | |
| LS-TCL-2567 | 0.277x, WD 73 mm, 1/2.5", C-mount | 0.277 | 73±1 | 4.2 | $1,619.00 | View |
| LS-TCL-2569 | 0.2x, WD 110 mm, 1/2.5", C-mount | 0.200 | 110±2 | 4.2 | $1,859.00 | View |
| LS-TCL-2570 | 0.199x, WD 111 mm, 1/2.5", C-Mount | 0.199 | 111±2 | $1,879.00 | View | |
| LS-TCL-2572 | 0.172x, WD 119 mm, 1/2.5", C-Mount | 0.172 | 119±2 | $2,139.00 | View | |
| LS-TCL-2571 | 0.171x, WD 118 mm, 1/2.5", C-mount | 0.171 | 118±3 | 4.2 | $2,139.00 | View |
| LS-TCL-2574 | 0.15x, WD 128 mm, 1/2.5", C-Mount | 0.150 | 128±2 | $2,469.00 | View | |
| LS-TCL-2575 | 0.15x, WD 138 mm, 1/2.5", C-mount | 0.150 | 138±3 | 4.2 | $2,469.00 | View |
| LS-TCL-2573 | 0.15x, WD 128 mm, 1/2.5", C-mount | 0.150 | 128±3 | 4.2 | $2,469.00 | View |
| LS-TCL-2576 | 0.129x, WD 138 mm, 1/2.5", C-Mount | 0.129 | 138±2 | 4.2 | $2,599.00 | View |
| LS-TCL-2577 | 0.113x, WD 187 mm, 1/2.5", C-Mount | 0.113 | 187±2 | 4.2 | $2,699.00 | View |
| LS-TCL-2578 | 0.112x, WD 159 mm, 1/2.5", C-Mount | 0.112 | 159±2 | 4.2 | $2,699.00 | View |
| LS-TCL-2579 | 0.1x, WD 178 mm, 1/2.5", C-Mount | 0.100 | 178±2 | 4.2 | $2,699.00 | View |
| LS-TCL-2580 | 0.09x, WD 229 mm, 1/2.5", C-Mount | 0.090 | 229±2 | 4.2 | $2,899.00 | View |
| LS-TCL-2581 | 0.08x, WD 208 mm, 1/2.5", C-mount | 0.080 | 208±3 | 4.2 | $3,069.00 | View |
| LS-TCL-2583 | 0.065x, WD 251 mm, 1/2.5", C-Mount | 0.065 | 251±3 | 4 | $3,649.00 | View |
| LS-TCL-2582 | 0.077x, WD 254 mm, 1/2.5", C-Mount | 0.077 | 254±3 | $4,299.00 | View | |
| LS-TCL-2584 | 0.06x, WD 280 mm, 1/2.5", C-mount | 0.060 | 280±5 | 4.2 | $4,649.00 | View |
| LS-TCL-2587 | 0.042x, WD 318 mm, 1/2.5", C-Mount | 0.042 | 318±4 | 4.2 | $4,779.00 | View |
| LS-TCL-2585 | 0.053x, WD 288 mm, 1/2.5", C-Mount | 0.053 | 288±4 | 3.8 | $5,319.00 | View |
| LS-TCL-2588 | 0.038x, WD 330 mm, 1/2.5", C-mount | 0.038 | 330±5 | 4.2 | $5,369.00 | View |
| LS-TCL-2586 | 0.048x, WD 301 mm, 1/2.5", C-Mount | 0.048 | 301±4 | 4.2 | $5,429.00 | View |
| LS-TCL-2591 | 0.027x, WD 438 mm, 1/2.5", C-Mount | 0.027 | 438±6 | 4.2 | $5,839.00 | View |
| LS-TCL-2589 | 0.033x, WD 372 mm, 1/2.5", C-mount | 372±5 | 4.2 | $6,029.00 | View | |
| LS-TCL-2590 | 0.03x, WD 410 mm, 1/2.5", C-Mount | 0.030 | 410±5 | 4.2 | $6,659.00 | View |
| LS-TCL-2592 | 0.024x, WD 465 mm, 1/2.5", C-Mount | 0.024 | 465±6 | 4.2 | $7,269.00quote | View |
