Hikrobot MV-PE5715 Time-of-flight sensor(5m, Infrared Laser, Class1)
Model MV-PE5715Hikrobot
- Range50 mm to 5000 mm
- Light sourceInfrared laser 905 nm
- Response500 μs/10 ms switch
- Supply12 VDC to 24 VDC ± 10%
$49.00
Quoted price: add to quote for lead time and volume pricing.
End of life soon: the maker is phasing this model out, so stock is limited. Ask us for availability or the successor model.
Ships in 2-3 weeks
0.16 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-PE5715 Time-of-flight sensor(5m, Infrared Laser, Class1). Remains unaffected by material and color based on the time-of-flight principle. Provides a teach-in button with ease of use.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-PE5715 |
|---|---|
| Brand | Hikrobot |
| Detecting distance | 50 mm to 5000 mm |
| Sensing target | Standard reflector (100 mm × 100 mm) with reflectivity of 90% |
| Response time | 500 μs/10 ms switch |
| Laser safety class | Class 1 |
| Method of setting up | Single teach-in button |
| Insulation resistance | 20 MΩ or more (between the terminal block for power supply and the housing) |
| Indicator | Operation indicator: orange; Stability indicator: green |
| Connecting method | Cable lead-out (standard length: 2 m, 78.7") |
Light
| Light source | Infrared laser 905 nm |
|---|---|
| Ambient illumination | Sunlight: < 10000 lux; Incandescent lamp: < 3000 lux |
Environment and compliance
| Temperature | Working temperature: –25 °C to 55 °C (–13 °F to 131 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
|---|---|
| Humidity | 35% RH to 85% RH |
| Ingress protection | IP67 |
| Vibration resistance | 10 Hz to 500 Hz, double amplitude 1.5 mm (0.1"), 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 500 m/s2, 3 times in each of the X, Y, and Z directions |
| Certification | CE, RoHS |
Electrical
| Output | NPN/PNP switch and light-on/dark-on switch |
|---|---|
| Supply voltage | 12 VDC to 24 VDC ± 10% |
| Residual voltage | ≤ 2 VDC |
| Operating current | ≤ 35 mA @ 12V, ≤ 20 mA @ 24V |
| Max. sink/source current | ≤ 100 mA |
| Circuit protection | Reverse polarity protection, overcurrent protection, and overvoltage protection |
| Withstand voltage | 1000 VAC, 1 min (between the terminal block for power supply and the housing) |
Mechanical
| Dimension | 20 mm × 12 mm × 31.6 mm (0.8" × 0.5" × 1.2") |
|---|---|
| Weight | Approx. 45 g (0.1 lb.) (including cable) |
| Material | Housing: polycarbonate; Lens: acrylic |
| Shipping weight (estimated) | 0.16 kg |
