Telecentric lens series, 2/3", C-mount (S19)

Telecentric lenses

Telecentric lens series, 2/3", C-mount (S19)

  • 9 models
  • from $3,619.00
  • Series LS-TCL-S19

The Telecentric lens series, 2/3", C-mount (S19) is a range of 9 telecentric lenses from LumaSpec Vision, from $3,619.00. It comes in 9 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Build a system with this series See all 9 models Series datasheet (PDF)

The series at a glance

Sizes / versions
0.093×, 0.11×, 0.138×, 0.157×, 0.184×, 0.243×, 0.35×, 0.528×, 1×
Mount
C-mount
Image circle
8-11 mm
Type
Object-side telecentric
Magnification
Under 0.1x, 0.1-0.3x, 0.3-0.6x, 1-2x
Working distance
Under 65 mm, 65-110 mm, 110-200 mm, 200 mm +
Sensor format
2/3"

All 9 models in the Telecentric lens series, 2/3", C-mount (S19)

Link
LS-TCL-03381×7 μm62.2 mm285 x 56 x 79 mm$3,619.00quoteView
LS-TCL-03390.528×10 μm43.1 mm311 x 66 x 81 mm$4,119.00quoteView
LS-TCL-03400.35×15 μm67.2 mm389 x 66 x 81 mm$4,389.00quoteView
LS-TCL-03410.243×21 μm102.5 mm545 x 103 x 141 mm$5,969.00quoteView
LS-TCL-03420.184×28 μm132.9 mm653 x 117 x 148 mm$6,539.00quoteView
LS-TCL-03430.157×32 μm157.8 mm712 x 122 x 150 mm$7,129.00quoteView
LS-TCL-03440.138×37 μm181.8 mm845 x 143 x 161 mm$8,699.00quoteView
LS-TCL-03450.11×46 μm226.7 mm936 x 158 x 168 mm$10,499.00quoteView
LS-TCL-03460.093×55 μm278.6 mm1084 x 185 x 207 mm$12,639.00quoteView
