Telecentric lens series, 1/1.2", C-mount (S23)

Telecentric lenses

Telecentric lens series, 1/1.2", C-mount (S23)

  • 6 models
  • from $3,989.00
  • Series LS-TCL-S23

The Telecentric lens series, 1/1.2", C-mount (S23) is a range of 6 telecentric lenses from LumaSpec Vision, from $3,989.00. It comes in 6 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Build a system with this series See all 6 models Series datasheet (PDF)

The series at a glance

Sizes / versions
0.087×, 0.114×, 0.134×, 0.166×, 0.19×, 0.222×
Mount
C-mount
Image circle
11-16 mm
Type
Object-side telecentric
Magnification
Under 0.1x, 0.1-0.3x
Working distance
110-200 mm, 200 mm +
Sensor format
1/1.2"

All 6 models in the Telecentric lens series, 1/1.2", C-mount (S23)

Link
LS-TCL-03650.222×23 μm132.4 mm144.7 x 106 x 77 mm$3,989.00quoteView
LS-TCL-03660.19×27 μm157.8 mm154.3 x 110 x 94 mm$4,239.00quoteView
LS-TCL-03670.166×31 μm181.9 mm161.9 x 122 x 101 mm$4,609.00quoteView
LS-TCL-03680.134×38 μm226.8 mm180.9 x 145 x 119 mm$5,349.00quoteView
LS-TCL-03690.114×45 μm278.6 mm197.5 x 172 x 139 mm$6,219.00quoteView
LS-TCL-03700.087×58 μm334.6 mm230.3 x 220 x 181 mm$8,089.00quoteView
