Telecentric lens series, 4K

Telecentric lenses

Telecentric lens series, 4K

  • 9 models
  • from $4,019.00
  • Series LS-TCL-S17

The Telecentric lens series, 4K is a range of 9 telecentric lenses from LumaSpec Vision, from $4,019.00. It comes in 4 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Build a system with this series See all 9 models Series datasheet (PDF)

The series at a glance

Sizes / versions
0.159×, 0.24×, 0.319×, 0.478×
Mount
M42, F-mount
Image circle
22-30 mm
Type
Object-side telecentric
Magnification
0.1-0.3x, 0.3-0.6x
Working distance
110-200 mm, 200 mm +
Sensor format
4/3" - APS-C

All 9 models in the Telecentric lens series, 4K

Link
LS-TCL-02810.478×21 μm174 mmF-mount$4,019.00quoteView
LS-TCL-02820.478×21 μm174 mmM42-mount$4,019.00quoteView
LS-TCL-02830.319×32 μm174 mmF-mount$5,129.00quoteView
LS-TCL-02840.319×32 μm174 mmM42-mount$5,129.00quoteView
LS-TCL-02850.319×32 μm174 mmM42-mount$5,129.00quoteView
LS-TCL-02860.24×42 μm174 mmF-mount$6,119.00quoteView
LS-TCL-02870.24×42 μm174 mmM42-mount$6,119.00quoteView
LS-TCL-02880.159×64 μm254 mmF-mount$8,399.00quoteView
LS-TCL-02890.159×64 μm254 mmM42-mount$8,399.00quoteView
