Telecentric lens series, 1.1", C-mount (S24)

Telecentric lenses

Telecentric lens series, 1.1", C-mount (S24)

  • 6 models
  • from $4,029.00
  • Series LS-TCL-S24

The Telecentric lens series, 1.1", C-mount (S24) is a range of 6 telecentric lenses from LumaSpec Vision, from $4,029.00. It comes in 6 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Build a system with this series See all 6 models Series datasheet (PDF)

The series at a glance

Sizes / versions
0.118×, 0.153×, 0.182×, 0.227×, 0.259×, 0.303×
Mount
C-mount
Image circle
16-22 mm
Type
Object-side telecentric
Magnification
0.1-0.3x, 0.3-0.6x
Working distance
110-200 mm, 200 mm +
Sensor format
1.1" - 1.2"

All 6 models in the Telecentric lens series, 1.1", C-mount (S24)

Link
LS-TCL-03800.303×17 μm132.9 mm152.3 x 106 x 77 mm$4,029.00quoteView
LS-TCL-03810.259×20 μm157.8 mm162.3 x 110 x 94 mm$4,269.00quoteView
LS-TCL-03820.227×22 μm181.9 mm169.9 x 122 x 101 mm$4,649.00quoteView
LS-TCL-03830.182×28 μm226.8 mm189 x 145 x 119 mm$5,399.00quoteView
LS-TCL-03840.153×33 μm278.6 mm208.3 x 172 x 139 mm$6,269.00quoteView
LS-TCL-03850.118×43 μm334.6 mm238.6 x 220 x 181 mm$8,159.00quoteView
