Telecentric lenses
Bi-telecentric lens for 2/3" sensor (LS-TCL-S97)
- 25 models
- from $909.00
- Series LS-TCL-S97
The Bi-telecentric lens for 2/3" sensor (LS-TCL-S97) is a range of 25 telecentric lenses from LumaSpec Vision, from $909.00. It comes in 20 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 0.063x, WD 320 mm, 2/3", C-mount, 0.095x, WD 250 mm, 2/3", C-mount, 0.12x, WD 250 mm, 2/3", C-mount, 0.14x, WD 200 mm, 2/3", C-mount, 0.15x, WD 238 mm, 2/3", C-mount, 0.178x, WD 158 mm, 2/3", C-mount, 0.2x, WD 178 mm, 2/3", C-mount, 0.22x, WD 200 mm, 2/3", C-mount, 0.265x, WD 178 mm, 2/3", C-mount, 0.3x, WD 110 mm, 2/3", C-mount, 0.3x, WD 178 mm, 2/3", C-mount, 0.5x, WD 110 mm, 2/3", C-mount, 0.5x, WD 178 mm, 2/3", C-mount, 0.5x, WD 275 mm, 2/3", C-mount, 0.78x, WD 290 mm, 2/3", C-mount, 0.8x, WD 110 mm, 2/3", C-mount and 4 more
- Mount
- C-mount
- Image circle
- Up to 8 mm
- Type
- Bi-telecentric
- Coaxial light
- Built-in coaxial light, No coaxial port
- Working distance
- 110-200 mm, 200 mm +
- Sensor format
- 2/3"
- Magnification
- Under 0.1x, 0.1-0.3x, 0.3-0.6x, 0.6-1x, 1-2x, 2x +
Features
- Supports cameras with sensors up to 2/3" (dia. 11 mm)
- Excellent double-sided telecentric optical path, ultra-low distortion design
- Very large depth of field to image products at different heights
- High-precision alignment: measurement error < 0.3 pixel over the full field of view
- Lightweight, purpose-built structure performs stably during high-speed motion
All 25 models in the Bi-telecentric lens for 2/3" sensor (LS-TCL-S97)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-TCL-3056 | WD 110 mm, 2/3", C-mount | 110 | F9 | φ5.5 | $909.00 | View |
| LS-TCL-3061 | 0.5x, WD 110 mm, 2/3", C-mount | 110 | F8 | φ22 | $1,189.00 | View |
| LS-TCL-3062 | 0.5x, WD 110 mm, 2/3", C-mount | 110 | F8 | φ22 | $1,189.00 | View |
| LS-TCL-3063 | 0.5x, WD 178 mm, 2/3", C-mount | 178 | F9 | φ22 | $1,189.00 | View |
| LS-TCL-3064 | 0.5x, WD 275 mm, 2/3", C-mount | 275 | F9 | φ22 | $1,189.00 | View |
| LS-TCL-3065 | 0.8x, WD 110 mm, 2/3", C-mount | 110 | F9 | φ13.7 | $1,199.00 | View |
| LS-TCL-3066 | 0.8x, WD 110 mm, 2/3", C-mount | 110 | F9 | φ13.7 | $1,199.00 | View |
| LS-TCL-3055 | 2x, WD 110 mm, 2/3", C-mount | 110 | F9 | φ5.5 | $1,239.00 | View |
| LS-TCL-3053 | 1.5x, WD 110 mm, 2/3", C-mount | 110 | F9 | φ7.3 | $1,239.00 | View |
| LS-TCL-3054 | 1.5x, WD 110 mm, 2/3", C-mount | 110 | F9 | φ7.3 | $1,239.00 | View |
| LS-TCL-3051 | 1x, WD 110 mm, 2/3", C-mount | 110 | F7 | φ11 | $1,239.00 | View |
| LS-TCL-3052 | 1x, WD 110 mm, 2/3", C-mount | 110 | F7 | φ11 | $1,239.00 | View |
| LS-TCL-3058 | 0.3x, WD 110 mm, 2/3", C-mount | 110 | F7 | φ36.6 | $1,529.00 | View |
| LS-TCL-3059 | 0.3x, WD 110 mm, 2/3", C-mount | 110 | F7 | φ36.6 | $1,529.00 | View |
| LS-TCL-3060 | 0.3x, WD 178 mm, 2/3", C-mount | 178 | F6 | φ36.6 | $1,529.00 | View |
| LS-TCL-3075 | 0.265x, WD 178 mm, 2/3", C-mount | 178 | F6 | φ41.5 | $1,529.00 | View |
| LS-TCL-3070 | 0.22x, WD 200 mm, 2/3", C-mount | 200 | F6 | φ50 | $1,679.00 | View |
| LS-TCL-3057 | 0.2x, WD 178 mm, 2/3", C-mount | 178 | F7 | φ55 | $1,769.00 | View |
| LS-TCL-3069 | 0.15x, WD 238 mm, 2/3", C-mount | 238 | F6.5 | φ73.3 | $2,089.00 | View |
| LS-TCL-3074 | 0.178x, WD 158 mm, 2/3", C-mount | 158 | F5.3 | φ61.7 | $2,139.00 | View |
| LS-TCL-3068 | 0.14x, WD 200 mm, 2/3", C-mount | 200 | F6.5 | φ78.5 | $2,179.00 | View |
| LS-TCL-3067 | 0.12x, WD 250 mm, 2/3", C-mount | 250 | F8 | φ91.6 | $2,409.00 | View |
| LS-TCL-3073 | 0.095x, WD 250 mm, 2/3", C-mount | 250 | F7.5 | φ115.7 | $2,839.00 | View |
| LS-TCL-3072 | 0.78x, WD 290 mm, 2/3", C-mount | 290 | F5 | φ141 | $3,269.00 | View |
| LS-TCL-3071 | 0.063x, WD 320 mm, 2/3", C-mount | 320 | F5 | φ174.6 | $3,859.00 | View |
