Telecentric lenses
Bi-telecentric lens for 1.1" sensor (LS-TCL-S96)
- 23 models
- from $1,129.00
- Series LS-TCL-S96
The Bi-telecentric lens for 1.1" sensor (LS-TCL-S96) is a range of 23 telecentric lenses from LumaSpec Vision, from $1,129.00. It comes in 22 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 0.078x, WD 410 mm, 1.1", C-mount, 0.11x, WD 320 mm, 1.1", C-mount, 0.13x, WD 300 mm, 1.1", C-mount, 0.153x, WD 250 mm, 1.1", C-mount, 0.172x, WD 230 mm, 1.1", C-mount, 0.2x, WD 250 mm, 1.1", C-mount, 0.22x, WD 200 mm, 1.1", C-mount, 0.25x, WD 230 mm, 1.1", C-mount, 0.275x, WD 200 mm, 1.1", C-mount, 0.3x, WD 200 mm, 1.1", C-mount, 0.345x, WD 178 mm, 1.1", C-mount, 0.4x, WD 178 mm, 1.1", C-mount, 0.5x, WD 220 mm, 1.1", C-mount, 0.52x, WD 110 mm, 1.1", C-mount, 0.6x, WD 190 mm, 1.1", C-mount, 0.7x, WD 110 mm, 1.1", C-mount and 6 more
- Mount
- C-mount
- Image circle
- 16-22 mm
- Type
- Bi-telecentric
- Coaxial light
- Built-in coaxial light, No coaxial port
- Magnification
- Under 0.1x, 0.1-0.3x, 0.3-0.6x, 0.6-1x, 1-2x
- Working distance
- 110-200 mm, 200 mm +
- Sensor format
- 1.1" - 1.2"
Features
- Supports cameras with sensors up to 1.1" (dia. 19.5 mm)
- Excellent double-sided telecentric optical path, ultra-low distortion design
- Very large depth of field to image products at different heights
- High-precision alignment: hardware measurement error < 0.3 pixel over the full field of view
- Lightweight, secure structure performs stably during high-speed motion
All 23 models in the Bi-telecentric lens for 1.1" sensor (LS-TCL-S96)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-TCL-3028 | 1x, WD 110 mm, 1.1", C-mount | 110 | F7 | 18.5 | $1,129.00 | View |
| LS-TCL-3050 | 1x, WD 110 mm, 1.1", C-mount | 110 | F7 | 18.5 | $1,129.00 | View |
| LS-TCL-3030 | 1x, WD 220 mm, 1.1", C-mount | 220 | F8.3 | 18.5 | $1,129.00 | View |
| LS-TCL-3029 | 1x, WD 178 mm, 1.1", C-mount | 178 | F11 | 18.5 | $1,129.00 | View |
| LS-TCL-3038 | 0.8x, WD 110 mm, 1.1", C-mount | 110 | F6 | 23.1 | $1,209.00 | View |
| LS-TCL-3039 | 0.8x, WD 220 mm, 1.1", C-mount | 220 | F8 | 23.1 | $1,209.00 | View |
| LS-TCL-3037 | 0.7x, WD 110 mm, 1.1", C-mount | 110 | F6 | 26.4 | $1,269.00 | View |
| LS-TCL-3036 | 0.6x, WD 190 mm, 1.1", C-mount | 190 | F8 | 30.8 | $1,349.00 | View |
| LS-TCL-3044 | 0.52x, WD 110 mm, 1.1", C-mount | 110 | F6 | 35.5 | $1,429.00 | View |
| LS-TCL-3035 | 0.5x, WD 220 mm, 1.1", C-mount | 220 | F8 | 37 | $1,459.00 | View |
| LS-TCL-3031 | 1.5x, WD 110 mm, 1.1", C-mount | 110 | F11 | 12.3 | $1,469.00 | View |
| LS-TCL-3034 | 0.4x, WD 178 mm, 1.1", C-mount | 178 | F6 | 46.25 | $1,619.00 | View |
| LS-TCL-3049 | 0.345x, WD 178 mm, 1.1", C-mount | 178 | F6 | 53.6 | $1,749.00 | View |
| LS-TCL-3033 | 0.3x, WD 200 mm, 1.1", C-mount | 200 | F6 | 61.6 | $1,889.00 | View |
| LS-TCL-3048 | 0.275x, WD 200 mm, 1.1", C-mount | 200 | F6 | 67.2 | $1,989.00 | View |
| LS-TCL-3043 | 0.25x, WD 230 mm, 1.1", C-mount | 230 | F6 | 74 | $2,109.00 | View |
| LS-TCL-3042 | 0.22x, WD 200 mm, 1.1", C-mount | 200 | F5.3 | 84 | $2,289.00 | View |
| LS-TCL-3032 | 0.2x, WD 250 mm, 1.1", C-mount | 250 | F10 | 92.5 | $2,439.00 | View |
| LS-TCL-3047 | 0.172x, WD 230 mm, 1.1", C-mount | 230 | F5.6 | 107.5 | $2,699.00 | View |
| LS-TCL-3046 | 0.153x, WD 250 mm, 1.1", C-mount | 250 | F5.6 | 120.9 | $2,939.00 | View |
| LS-TCL-3041 | 0.13x, WD 300 mm, 1.1", C-mount | 300 | F6 | 107.5 | $3,309.00 | View |
| LS-TCL-3040 | 0.11x, WD 320 mm, 1.1", C-mount | 320 | F7 | 107.5 | $3,759.00 | View |
| LS-TCL-3045 | 0.078x, WD 410 mm, 1.1", C-mount | 410 | F7 | 107.5 | $6,039.00 | View |
