Machine vision lenses
Object-side telecentric and fixed-magnification lenses, C-mount (LS-TCL-S38)
- 56 models
- from $659.00
- Series LS-TCL-S38
The Object-side telecentric and fixed-magnification lenses, C-mount (LS-TCL-S38) is a range of 56 machine vision lenses from LumaSpec Vision, from $659.00. It comes in 56 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 0.1x, 778 mm WD, 1.2", 0.128x, 1115 mm WD, 1.1", 0.13x, 630 mm WD, 1.2", 0.14x, 700 mm WD, 1", 0.15x, 640 mm WD, 1.1", 0.15x, 963 mm WD, 1.1", 0.175x, 640 mm WD, 1", 0.18x, 630 mm WD, 1", 0.2x, 550 mm WD, 1", 0.2x, 604 mm WD, 1.2", 0.2x, 750 mm WD, 1.1", 0.22x, 380 mm WD, 1", 0.22x, 530 mm WD, 1", 0.24x, 760 mm WD, 1", 0.25x, 310 mm WD, 1.2", 0.25x, 415 mm WD, 4/3" and 40 more
- Mount
- C-mount
- Image circle
- 11-16 mm, 16-22 mm
- Sensor format
- 1", 1.1" - 1.2", 4/3" - APS-C
Features
- A smaller field than the 0.8x version
- Stays sharp over about 0.7 mm of height: parts must sit within ±0.35 mm of focus
- Covers sensors up to 1.1" (17.5 mm diagonal) without dark corners; a larger sensor would vignette
- One step down in the series is the 0.8x version
- Stays sharp over about 2 mm of height: parts must sit within ±1 mm of focus
- The 0.8x version is one step down in this series
- 0.3559 % distortion: a corner point of the 21.9 mm field lands within about 38.9 µm of its true place
- Sits between the 0.7x and 1x versions of this series
All 56 models in the Object-side telecentric and fixed-magnification lenses, C-mount (LS-TCL-S38)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-TCL-0567 | 1x, 221 mm WD, 1.1" | 1x | 221 mm | F9 | $659.00 | View |
| LS-TCL-0659 | 1x, 370 mm WD, 1.1" | 1x | 370 mm | F25 | $689.00 | View |
| LS-TCL-0568 | 1x, 375 mm WD, 1.1" | 1x | 375 mm | F9.5 | $689.00 | View |
| LS-TCL-0581 | 0.8x, 421 mm WD, 1.1" | 0.8x | 421 mm | F9 | $689.00 | View |
| LS-TCL-0580 | 0.8x, 135 mm WD, 1.2" | 0.8x | 135 mm | F9.2 | $739.00 | View |
| LS-TCL-0673 | 0.7x, 135 mm WD, 1" | 0.7x | 135 mm | F15.5 | $759.00 | View |
| LS-TCL-0688 | 0.65x, 360 mm WD, 4/3" | 0.65x | 360 mm | F36.3 | $789.00 | View |
| LS-TCL-0670 | 0.5x, 240 mm WD, 1" | 0.5x | 240 mm | F12.5 | $799.00 | View |
| LS-TCL-0671 | 0.5x, 360 mm WD, 4/3" | 0.5x | 360 mm | F38.3 | $829.00 | View |
| LS-TCL-0669 | 0.4x, 550 mm WD, 1.1" | 0.4x | 550 mm | F13.2 | $829.00 | View |
| LS-TCL-0578 | 0.5x, 363 mm WD, 1.1" | 0.5x | 363 mm | F7.5 | $829.00 | View |
| LS-TCL-0593 | 0.45x, 610 mm WD, 1.1" | 0.45x | 610 mm | F8 | $829.00 | View |
| LS-TCL-0577 | 0.5x, 316 mm WD, 1.2" | 0.5x | 316 mm | F12 | $829.00 | View |
| LS-TCL-0663 | 0.3x, 193 mm WD, 1" | 0.3x | 193 mm | F16.8 | $969.00 | View |
| LS-TCL-0576 | 0.4x, 670 mm WD, 1.1" | 0.4x | 670 mm | F8 | $1,089.00 | View |
| LS-TCL-0672 | 0.6x, 220 mm WD, 1" | 0.6x | 220 mm | F12.9 | $1,119.00 | View |
| LS-TCL-0666 | 0.3x, 650 mm WD, 1.1" | 0.3x | 650 mm | F10.5 | $1,339.00 | View |
| LS-TCL-0686 | 0.35x, 560 mm WD, 1.1" | 0.35x | 560 mm | F12.5 | $1,339.00 | View |
| LS-TCL-0589 | 0.35x, 473 mm WD, 1.1" | 0.35x | 473 mm | F7 | $1,339.00 | View |
| LS-TCL-0572 | 0.3x, 534 mm WD, 1.1" | 0.3x | 534 mm | F7 | $1,339.00 | View |
| LS-TCL-0591 | 0.35x, 733 mm WD, 1.1" | 0.35x | 733 mm | F8 | $1,339.00 | View |
| LS-TCL-0590 | 0.35x, 647 mm WD, 1.1" | 0.35x | 647 mm | F8.7 | $1,339.00 | View |
| LS-TCL-0687 | 0.36x, 125 mm WD, 1" | 0.36x | 125 mm | F14.9 | $1,379.00 | View |
| LS-TCL-0587 | 0.35x, 232 mm WD, 1.2" | 0.35x | 232 mm | F5.6 | $1,449.00 | View |
| LS-TCL-0592 | 0.45x, 189 mm WD, 1.2" | 0.45x | 189 mm | F6.5 | $1,649.00 | View |
| LS-TCL-0573 | 0.4x, 190 mm WD, 1.2" | 0.4x | 190 mm | F5.7 | $1,789.00 | View |
| LS-TCL-0674 | 0.7x, 300 mm WD, 1.1" | 0.7x | 300 mm | F17.9 | $1,929.00 | View |
| LS-TCL-0579 | 0.7x, 287 mm WD, 1.1" | 0.7x | 287 mm | F8 | $1,929.00 | View |
| LS-TCL-0574 | 0.4x, 227 mm WD, 1.2" | 0.4x | 227 mm | F6.9 | $2,269.00 | View |
| LS-TCL-0667 | 0.4x, 250 mm WD, 1" | 0.4x | 250 mm | F11 | $2,439.00 | View |
| LS-TCL-0588 | 0.35x, 254 mm WD, 1.2" | 0.35x | 254 mm | F6.6 | $2,439.00 | View |
| LS-TCL-0668 | 0.4x, 300 mm WD, 4/3" | 0.4x | 300 mm | F15 | $3,469.00 | View |
| LS-TCL-0585 | 0.25x, 310 mm WD, 1.2" | 0.25x | 310 mm | F4.9 | $3,469.00 | View |
| LS-TCL-0575 | 0.4x, 425 mm WD, 1.1" | 0.4x | 425 mm | F7 | $3,469.00 | View |
| LS-TCL-0664 | 0.3x, 340 mm WD, 1" | 0.3x | 340 mm | F14.1 | $3,819.00 | View |
| LS-TCL-0678 | 0.22x, 380 mm WD, 1" | 0.22x | 380 mm | F12.3 | $4,259.00 | View |
| LS-TCL-0665 | 0.3x, 360 mm WD, 1" | 0.3x | 360 mm | F12.9 | $4,259.00 | View |
| LS-TCL-0583 | 0.15x, 640 mm WD, 1.1" | 0.15x | 640 mm | F8 | $4,259.00 | View |
| LS-TCL-0584 | 0.15x, 963 mm WD, 1.1" | 0.15x | 963 mm | F6.5 | $4,259.00 | View |
| LS-TCL-0689 | 0.175x, 640 mm WD, 1" | 0.175x | 640 mm | F10.9 | $4,669.00 | View |
| LS-TCL-0677 | 0.18x, 630 mm WD, 1" | 0.18x | 630 mm | F5.6 | $4,669.00 | View |
| LS-TCL-0681 | 0.25x, 415 mm WD, 4/3" | 0.25x | 415 mm | F24.6 | $4,669.00 | View |
| LS-TCL-0684 | 0.28x, 680 mm WD, 1" | 0.28x | 680 mm | F11.8 | $4,669.00 | View |
| LS-TCL-0685 | 0.29x, 742 mm WD, 1" | 0.29x | 742 mm | F7.3 | $4,669.00 | View |
| LS-TCL-0586 | 0.25x, 423 mm WD, 1.2" | 0.25x | 423 mm | F8 | $4,669.00 | View |
| LS-TCL-0594 | 0.128x, 1115 mm WD, 1.1" | 0.128x | 1115 mm | F6 | $4,669.00 | View |
| LS-TCL-0569 | 0.1x, 778 mm WD, 1.2" | 0.1x | 778 mm | F5.1 | $4,669.00 | View |
| LS-TCL-0679 | 0.22x, 530 mm WD, 1" | 0.22x | 530 mm | F10.9 | $5,699.00quote | View |
| LS-TCL-0662 | 0.2x, 550 mm WD, 1" | 0.2x | 550 mm | F13.6 | $5,699.00quote | View |
| LS-TCL-0680 | 0.24x, 760 mm WD, 1" | 0.24x | 760 mm | F11.2 | $5,699.00quote | View |
| LS-TCL-0682 | 0.25x, 465 mm WD, 1" | 0.25x | 465 mm | F10 | $5,699.00quote | View |
| LS-TCL-0683 | 0.25x, 695 mm WD, 4/3" | 0.25x | 695 mm | F12.5 | $5,699.00quote | View |
| LS-TCL-0676 | 0.14x, 700 mm WD, 1" | 0.14x | 700 mm | F12 | $5,699.00quote | View |
| LS-TCL-0570 | 0.2x, 604 mm WD, 1.2" | 0.2x | 604 mm | F7.1 | $5,699.00quote | View |
| LS-TCL-0571 | 0.2x, 750 mm WD, 1.1" | 0.2x | 750 mm | F6.5 | $5,699.00quote | View |
| LS-TCL-0582 | 0.13x, 630 mm WD, 1.2" | 0.13x | 630 mm | F6 | $5,699.00quote | View |
