Machine vision lenses
Large-format telecentric and fixed-magnification lenses up to 24K, some with manual iris (LS-TCL-S57)
- 7 models
- from $1,829.00
- Series LS-TCL-S57
The Large-format telecentric and fixed-magnification lenses up to 24K, some with manual iris (LS-TCL-S57) is a range of 7 machine vision lenses from LumaSpec Vision, from $1,829.00. It comes in 7 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 0.17x, WD 185 mm, 1/2.3", C-mount, 0.171x, WD 150 mm, 1/2.3", C-mount, 0.179x, WD 150 mm, 2/3", C-mount, 0.191x, WD 135 mm, 1/1.7", C-mount, 0.286x, WD 180 mm, 1", C-mount, 0.353x, WD 108 mm, 1.1", C-mount, 0.36x, WD 90 mm, 1", C-mount
- Type
- Telecentric
- Mount
- C-mount
- Image circle
- Up to 8 mm, 8-11 mm, 11-16 mm, 16-22 mm
- Sensor format
- 1/2", 1/1.8" - 1/1.56", 2/3", 1", 1.1" - 1.2"
Features
- 0.04 % distortion: a corner point of the 44.4 mm field lands within about 8.9 µm of its true place
- One step down in the series is the 0.353x version
- Stays sharp over about 4 mm of height: parts must sit within ±2 mm of focus
- Separates details about 12 µm apart on the part: about 3,000 across the 35.6 mm wide field
- Covers sensors up to 1" (16 mm diagonal) without dark corners; a larger sensor would vignette
- 0.05 % distortion: a corner point of the 46.8 mm field lands within about 11.7 µm of its true place
- A larger field than 5 of the 6 other lenses in the series
- Covers sensors up to 1/2.3" (8 mm diagonal) without dark corners; a larger sensor would vignette
All 7 models in the Large-format telecentric and fixed-magnification lenses up to 24K, some with manual iris (LS-TCL-S57)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-TCL-1317 | 0.36x, WD 90 mm, 1", C-mount | 1" | 0.36 | 90 | $1,829.00 | View |
| LS-TCL-1368 | 0.171x, WD 150 mm, 1/2.3", C-mount | 1/2.3" | 0.171 | 150 | $1,879.00 | View |
| LS-TCL-1365 | 0.191x, WD 135 mm, 1/1.7", C-mount | 1/1.7" | 0.191 | 135 | $1,939.00 | View |
| LS-TCL-1327 | 0.353x, WD 108 mm, 1.1", C-mount | 1.1" | 0.353 | 108 | $1,999.00 | View |
| LS-TCL-1318 | 0.286x, WD 180 mm, 1", C-mount | 1" | 0.286 | 180 | $2,089.00 | View |
| LS-TCL-1369 | 0.17x, WD 185 mm, 1/2.3", C-mount | 0.17 | 185 | $2,139.00 | View | |
| LS-TCL-1389 | 0.179x, WD 150 mm, 2/3", C-mount | 2/3" | 0.179 | 150 | $2,209.00 | View |
