Machine vision lenses
SA series lenses
- 6 models
- from $269.00
- Series LS-SA
The SA series lenses is a range of 6 machine vision lenses from LumaSpec Vision, from $269.00. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Mount
- C-mount
- Image circle
- 22-30 mm
- Focal length
- 12-25 mm, 25-50 mm, 50-100 mm
- Resolution
- 6-10 MP
- Sensor format
- 4/3" - APS-C
Features
- High resolution and excellent image uniformity.
- F2.0, maximum format of 4/3''.
- Low distortion to improve measurement accuracy.
- High peripheral brightness ratio to ensure image brightness consistency.
- High resolution and excellent image uniformity
- F2.0, maximum image circle of 4/3''
- Low distortion to improve measurement accuracy
- High peripheral brightness ratio to ensure image brightness consistency
All 6 models in the SA series lenses
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-SA1220M-10MP | 12 mm | M77 × 0.75 | 0.15 m | –2.40% | $269.00 | View |
| LS-SA1620M-10MP | 16 mm | M58 × 0.75 | 0.1 m | –2.81% | $279.00 | View |
| LS-SA2520M-10MP | 25 mm | M40.5 × 0.75 | 0.15 m | –0.66% | $289.00 | View |
| LS-SA3520M-10MP | 35 mm | M40.5 × 0.75 | 0.2 m | –0.56% | $299.00 | View |
| LS-SA5020M-10MP | 50 mm | M40.5 × 0.5 | 0.3 m | –0.14% | $319.00 | View |
| LS-SA8520M-10MP | 85 mm | M77 × 0.75 | 1.2 m | –0.04% | $369.00 | View |
