Hole backlight (LS-BKL-S91)
- 22 models
- from $369.00
- Series LS-BKL-S91
The Hole backlight (LS-BKL-S91) is a range of 22 backlights from LumaSpec Vision, from $369.00. It comes in 22 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 150 x 150 mm, 200 x 100 mm, 200 x 200 mm, 250 x 250 mm, 300 x 200 mm, 300 x 300 mm, 350 x 350 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 450 x 450 mm, 500 x 300 mm, 500 x 400 mm, 500 x 500 mm, 600 x 400 mm, 600 x 600 mm and 6 more
- Colour
- Red, Blue, White
- Type
- With centre hole
- Voltage
- 24 V
- Connector
- SM3, WS20 4-pin
Features
- Backlight with a centre hole (K suffix in the model; drawing of LS-BKL-0691 shows a dia. 40 hole)
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Interface: SM3 (1.3 pin) up to 400 x 300; 4-pin WS16 aviation interface 400 x 400 to 600 x 400; 4-pin WS20 aviation interface 600 x 600 to 1000 x 1000
- Luminous size:150mm*150mm.Hole diameter:50mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:50000 hours for red light and 30000 hours for white light.
- Suitable for large area inspection such as large volume object measurement, robotic arm grasping illumination, contour detection and transparent object impurity detection.
Typical uses
- Measurement of the four dimensions of the object
- Edge breakage detection
- Transparent object impurity detection
- Phone case edge detection
- Sole contour detection
All 22 models in the Hole backlight (LS-BKL-S91)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BKL-0885 | 200 x 100 mm | 21 | 214 | 200x100 | $369.00 | View |
| LS-BKL-0884 | 150 x 150 mm | 20 | 185 | 150*150 | $389.00 | View |
| LS-BKL-0886 | 200 x 200 mm | 21 | 214 | 200x200 | $549.00 | View |
| LS-BKL-0888 | 300 x 200 mm | 21 | 314 | 300x200 | $719.00 | View |
| LS-BKL-0887 | 250 x 250 mm | 21 | 264 | 250x250 | $739.00 | View |
| LS-BKL-0891 | 400 x 200 mm | 21 | 414 | 400x200 | $889.00 | View |
| LS-BKL-0889 | 300 x 300 mm | 21 | 314 | 300x300 | $959.00 | View |
| LS-BKL-0895 | 500 x 300 mm | 31 | 514 | 500x300 | $1,039.00 | View |
| LS-BKL-0893 | 400 x 400 mm | 21 | 414 | 400x400 | $1,049.00 | View |
| LS-BKL-0892 | 400 x 300 mm | 21 | 414 | 400x300 | $1,199.00 | View |
| LS-BKL-0890 | 350 x 350 mm | 21 | 364 | 350x350 | $1,209.00 | View |
| LS-BKL-0896 | 500 x 400 mm | 31 | 514 | 500x400 | $1,269.00 | View |
| LS-BKL-0894 | 450 x 450 mm | 31 | 464 | 450x450 | $1,279.00 | View |
| LS-BKL-0898 | 600 x 400 mm | 31 | 614 | 600x400 | $1,489.00 | View |
| LS-BKL-0897 | 500 x 500 mm | 31 | 514 | 500x500 | $1,539.00 | View |
| LS-BKL-0900 | 700 x 500 mm | 31 | 714 | 700x500 | $2,079.00 | View |
| LS-BKL-0899 | 600 x 600 mm | 32 | 614 | 600x600 | $2,129.00 | View |
| LS-BKL-0902 | 800 x 600 mm | 32 | 814 | 800x600 | $2,779.00 | View |
| LS-BKL-0901 | 700 x 700 mm | 32 | 714 | 700x700 | $2,839.00 | View |
| LS-BKL-0903 | 800 x 800 mm | 32 | 814 | 800x800 | $3,639.00 | View |
| LS-BKL-0904 | 900 x 900 mm | 32 | 914 | 900x900 | $4,559.00 | View |
| LS-BKL-0905 | 1000 x 1000 mm | 32 | 1014 | 1000*1000 | $5,579.00 | View |
