Collimated Bottom Back Light (LS-BKL-S102)
- 13 models
- from $229.00
- Series LS-BKL-S102
The Collimated Bottom Back Light (LS-BKL-S102) is a range of 13 backlights from LumaSpec Vision, from $229.00. It comes in 13 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 27 x 27 mm, 43 x 35 mm, 50 x 50 mm, 63 x 60 mm, 83 x 75 mm, 100 x 100 mm, 120 x 120 mm, 140 x 105 mm, 160 x 120 mm, 200 x 150 mm, 200 x 50 mm, 211 x 200 mm, 224 x 170 mm
- Colour
- Red, Green, Blue, White
- Type
- Collimated
- Voltage
- 24 V
Features
- Flexible design for width, length, and overall dimensions.
- Effectively enhances product edge sharpness and contrast.
- High uniformity.
Typical uses
- Metal cylinder contour inspection, glass bottle diameter inspection, ceramic column diameter inspection, screw thread contour inspection.
- Transparent packaging box detection
- Contour defects
- Burrs on gold-plated components
- Coil burr detection
All 13 models in the Collimated Bottom Back Light (LS-BKL-S102)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BKL-1037 | 27 x 27 mm | 27x27 | 41x41x19 | 2.5 | $229.00 | View |
| LS-BKL-1038 | 43 x 35 mm | 43x35 | 57x49x19 | 2.5 | $229.00 | View |
| LS-BKL-1039 | 50 x 50 mm | 50x50 | 64x64x19 | 4.3 | $249.00 | View |
| LS-BKL-1040 | 63 x 60 mm | 63x60 | 77x74x19 | 5.3 | $259.00 | View |
| LS-BKL-1041 | 83 x 75 mm | 83x75 | 97x89x19 | 6.3 | $289.00 | View |
| LS-BKL-1042 | 100 x 100 mm | 100x100 | 114x114x19 | 6.6 | $329.00 | View |
| LS-BKL-1046 | 200 x 50 mm | 200x50 | 214x64x19 | 16.5 | $329.00 | View |
| LS-BKL-1043 | 120 x 120 mm | 120x120 | 134x134x19 | $379.00 | View | |
| LS-BKL-1044 | 140 x 105 mm | 140x105 | 154x119x19 | 9.9 | $389.00 | View |
| LS-BKL-1045 | 160 x 120 mm | 160x120 | 174x134x19 | 13.2 | $439.00 | View |
| LS-BKL-1047 | 200 x 150 mm | 200x150 | 214x164x19 | 19.8 | $569.00 | View |
| LS-BKL-1049 | 224 x 170 mm | 224x170 | 238x184x19 | 16.5 | $669.00 | View |
| LS-BKL-1048 | 211 x 200 mm | 211x200 | 225x214x19 | 21.8 | $709.00 | View |
