Backlights
Infrared light (LS-BKL-S69)
- 5 models
- from $209.00
- Series LS-BKL-S69
The Infrared light (LS-BKL-S69) is a range of 5 backlights from LumaSpec Vision, from $209.00. It comes in 5 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 50 x 50 mm, 70 x 70 mm, 80 x 80 mm, 100 x 100 mm, 150 x 150 mm
- Colour
- Infrared
- Type
- Standard
- Voltage
- 24 V
- Wavelength
- 940 nm
Features
- Strong penetration, wavelength optional: 850/940 nm
- Use with high sensitive CCD of near infrared field
- Use with infrared glass filter, adapts to strong ambient light
Typical uses
- Monitoring
- Packing (through the plastic packing)
- Foreign matter inspection in wine bottles
- Electronic, semiconductor inspection
- Imaging example: lingerie buckle inspection through clothing (LS-BKL-1343)
All 5 models in the Infrared light (LS-BKL-S69)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BKL-1340 | 50 x 50 mm | 50 x 50 | 2.4 | 101 | $209.00 | View |
| LS-BKL-1341 | 70 x 70 mm | 70 x 70 | 3.8 | 150 | $229.00 | View |
| LS-BKL-1342 | 80 x 80 mm | 80 x 80 | 4.3 | 175 | $249.00 | View |
| LS-BKL-1343 | 100 x 100 mm | 100 x 100 | 7.7 | 249 | $279.00 | View |
| LS-BKL-1344 | 150 x 150 mm | 150 x 150 | 11.5 | 463 | $389.00 | View |
