Hole backlight (LS-BKL-S80)
- 7 models
- from $319.00
- Series LS-BKL-S80
The Hole backlight (LS-BKL-S80) is a range of 7 backlights from LumaSpec Vision, from $319.00. It comes in 6 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 150 x 150 mm, 200 x 200 mm, 250 x 250 mm, 300 x 300 mm, 400 x 300 mm, 400 x 400 mm
- Type
- With centre hole
- Voltage
- 24 V
- Connector
- 3-pin flat
- Colour
- Blue, White
Features
- Backlight with a centre hole (K suffix in the model; drawing of LS-BKL-0691 shows a dia. 40 hole)
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Luminous size: 150mm*150mm. Hole diameter: 40mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:30000 hours for red light and 30000 hours for white light.
- Suitable for large area inspection such as large volume object measurement, robotic arm grasping illumination, contour detection and transparent object impurity detection.
Typical uses
- Measurement of the four dimensions of the object
- Edge breakage detection
- Transparent object impurity detection
- Phone case edge detection
- Sole contour detection
All 7 models in the Hole backlight (LS-BKL-S80)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BKL-0692 | $319.00 | View | ||||
| LS-BKL-0691 | 150 x 150 mm | 164 | 150x150 | 12.5 | $389.00 | View |
| LS-BKL-0693 | 200 x 200 mm | 214 | 200x200 | 20.9 | $549.00 | View |
| LS-BKL-0694 | 250 x 250 mm | 264 | 250x250 | 32.4 | $739.00 | View |
| LS-BKL-0695 | 300 x 300 mm | 414 | 300x300 | 53.7 | $999.00 | View |
| LS-BKL-0697 | 400 x 400 mm | 414 | 400x400 | 88 | $1,049.00 | View |
| LS-BKL-0696 | 400 x 300 mm | 414 | 400x300 | 67.4 | $1,189.00 | View |
