K Series Bi-Telecentric lenses

The K Series Bi-Telecentric lenses is a range of 37 telecentric lenses from LumaSpec Vision, from $859.00. It comes in 37 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Series datasheet (PDF)

Building a full system? Configure a camera, lens, light and controller that fit together →

The series at a glance

Sizes / versions	0.085x, 372 mm WD, 1.1", 0.087x, 330 mm WD, 1", 0.108x, 318 mm WD, 1.1", 0.122x, 288 mm WD, 1", 0.138x, 273 mm WD, 1", 0.153x, 273 mm WD, 1.1", 0.166x, 238 mm WD, 1", 0.167x, 263 mm WD, 1.1", 0.175x, 160 mm WD, 1.1", 0.184x, 208 mm WD, 1", 0.184x, 238 mm WD, 1.1", 0.204x, 208 mm WD, 1.1", 0.208x, 228 mm WD, 1", 0.23x, 228 mm WD, 1.1", 0.231x, 178 mm WD, 1", 0.256x, 178 mm WD, 1.1" and 21 more
Image circle	11-16 mm, 16-22 mm, 22-30 mm
Type	Bi-telecentric
Magnification	Under 0.1x, 0.1-0.3x, 0.3-0.6x, 0.6-1x
Working distance	Under 65 mm, 65-110 mm, 110-200 mm, 200 mm +
Mount	M42, M58, C-mount
Sensor format	1", 1.1" - 1.2", 4/3" - APS-C

Features

High resolution with consistent sharpness across the image
Low distortion and high telecentricity for high-precision measurement and positioning
Supports cameras up to 1.75"
Supports cameras up to 1"
Supports cameras up to 1.1"

All 37 models in the K Series Bi-Telecentric lenses

Model	Size	Price	Availability	Link
LS-KBT-0806-110-M42	0.806x, 110 mm WD, 1.75"	$859.00	3 in stock	View
LS-KBT-0503-48	0.503x, 48 mm WD, 1"	$929.00	5 in stock	View
LS-KBT-0634-45	0.634x, 45 mm WD, 1.1"	$999.00	3 in stock	View
LS-KBT-0708-73	0.708x, 73 mm WD, 1.1"	$999.00	5 in stock	View
LS-KBT-0638-73	0.638x, 73 mm WD, 1"	$999.00	4 in stock	View
LS-KBT-0511-110	0.511x, 110 mm WD, 1.1"	$1,019.00	5 in stock	View
LS-KBT-0377-82	0.377x, 82 mm WD, 1"	$1,029.00	4 in stock	View
LS-KBT-069-118-M42	0.69x, 118 mm WD, 1.75"	$1,109.00	3 in stock	View
LS-KBT-046-110	0.46x, 110 mm WD, 1"	$1,169.00	2 in stock	View
LS-KBT-0438-118	0.438x, 118 mm WD, 1.1"	$1,269.00	2 in stock	View
LS-KBT-0395-118	0.395x, 118 mm WD, 1"	$1,279.00	5 in stock	View
LS-KBT-0383-128	0.383x, 128 mm WD, 1.1"	$1,379.00	3 in stock	View
LS-KBT-0329-138	0.329x, 138 mm WD, 1.1"	$1,379.00	3 in stock	View
LS-KBT-0346-128	0.346x, 128 mm WD, 1"	$1,379.00	5 in stock	View
LS-KBT-0403-178-M58	0.403x, 178 mm WD, 1.75"	$1,519.00	4 in stock	View
LS-KBT-0296-138	0.296x, 138 mm WD, 1"	$1,599.00	5 in stock	View
LS-KBT-0288-158	0.288x, 158 mm WD, 1.1"	$1,609.00	2 in stock	View
LS-KBT-0256-178	0.256x, 178 mm WD, 1.1"	$1,649.00	3 in stock	View
LS-KBT-0175-160	0.175x, 160 mm WD, 1.1"	$1,649.00	5 in stock	View
LS-KBT-0322-208-M42	0.322x, 208 mm WD, 1.75"	$1,749.00	3 in stock	View
LS-KBT-0259-158	0.259x, 158 mm WD, 1"	$1,759.00	5 in stock	View
LS-KBT-0231-178	0.231x, 178 mm WD, 1"	$1,789.00	2 in stock	View
LS-KBT-0363-228-M42	0.363x, 228 mm WD, 1.75"	$1,809.00	3 in stock	View
LS-KBT-0230-228	0.23x, 228 mm WD, 1.1"	$1,909.00	2 in stock	View
LS-KBT-0208-228	0.208x, 228 mm WD, 1"	$1,929.00	2 in stock	View
LS-KBT-0204-208	0.204x, 208 mm WD, 1.1"	$1,929.00	3 in stock	View
LS-KBT-0184-208	0.184x, 208 mm WD, 1"	$2,099.00	4 in stock	View
LS-KBT-0184-238	0.184x, 238 mm WD, 1.1"	$2,229.00	4 in stock	View
LS-KBT-0166-238	0.166x, 238 mm WD, 1"	$2,269.00	2 in stock	View
LS-KBT-0167-263	0.167x, 263 mm WD, 1.1"	$2,269.00	2 in stock	View
LS-KBT-0153-273	0.153x, 273 mm WD, 1.1"	$2,529.00 quote	5 in stock	View
LS-KBT-0138-273	0.138x, 273 mm WD, 1"	$2,779.00 quote	5 in stock	View
LS-KBT-0122-288	0.122x, 288 mm WD, 1"	$2,889.00 quote	3 in stock	View
LS-KBT-0315-350-C	0.315x, 350 mm WD, 1.75"	$2,909.00 quote	5 in stock	View
LS-KBT-0108-318	0.108x, 318 mm WD, 1.1"	$3,049.00 quote	2 in stock	View
LS-KBT-0087-330	0.087x, 330 mm WD, 1"	$3,549.00 quote	2 in stock	View
LS-KBT-0085-372	0.085x, 372 mm WD, 1.1"	$3,679.00 quote	3 in stock	View
