Telecentric lenses · 23 models · from $719.00
Bi-telecentric lens for 1.1" sensor (XR-1CM)
The Bi-telecentric lens for 1.1" sensor (XR-1CM) is a range of 23 telecentric lenses from LumaSpec Vision, from $719.00. It comes in 22 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 0.078x, WD 410 mm, 1.1", C-mount, 0.11x, WD 320 mm, 1.1", C-mount, 0.13x, WD 300 mm, 1.1", C-mount, 0.153x, WD 250 mm, 1.1", C-mount, 0.172x, WD 230 mm, 1.1", C-mount, 0.2x, WD 250 mm, 1.1", C-mount, 0.22x, WD 200 mm, 1.1", C-mount, 0.25x, WD 230 mm, 1.1", C-mount, 0.275x, WD 200 mm, 1.1", C-mount, 0.3x, WD 200 mm, 1.1", C-mount, 0.345x, WD 178 mm, 1.1", C-mount, 0.4x, WD 178 mm, 1.1", C-mount, 0.5x, WD 220 mm, 1.1", C-mount, 0.52x, WD 110 mm, 1.1", C-mount, 0.6x, WD 190 mm, 1.1", C-mount, 0.7x, WD 110 mm, 1.1", C-mount and 6 more |
|---|---|
| Mount | C-mount |
| Image circle | 16-22 mm |
| Type | Bi-telecentric |
| Coaxial light | Built-in coaxial light, No coaxial port |
| Magnification | Under 0.1x, 0.1-0.3x, 0.3-0.6x, 0.6-1x, 1-2x |
| Working distance | 110-200 mm, 200 mm + |
| Sensor format | 1.1" - 1.2" |
Features
- Supports cameras with sensors up to 1.1" (dia. 19.5 mm)
- Excellent double-sided telecentric optical path, ultra-low distortion design
- Very large depth of field to image products at different heights
- High-precision alignment: hardware measurement error < 0.3 pixel over the full field of view
- Lightweight, secure structure performs stably during high-speed motion
All 23 models in the Bi-telecentric lens for 1.1" sensor (XR-1CM)
| Model | Size | Price | Availability | Link |
|---|---|---|---|---|
| LS-XR-1CM1.5-110 | 1.5x, WD 110 mm, 1.1", C-mount | $719.00 | 2 in stock | View |
| LS-XR-1CM1-110 | 1x, WD 110 mm, 1.1", C-mount | $799.00 | 2 in stock | View |
| LS-XR-1CMA-110C | 1x, WD 110 mm, 1.1", C-mount | $799.00 | 3 in stock | View |
| LS-XR-1CM1-220 | 1x, WD 220 mm, 1.1", C-mount | $799.00 | 4 in stock | View |
| LS-XR-1CM1-178 | 1x, WD 178 mm, 1.1", C-mount | $799.00 | 3 in stock | View |
| LS-XR-1CM08-110 | 0.8x, WD 110 mm, 1.1", C-mount | $859.00 | 5 in stock | View |
| LS-XR-1CM08-220 | 0.8x, WD 220 mm, 1.1", C-mount | $859.00 | 4 in stock | View |
| LS-XR-1CM07-110 | 0.7x, WD 110 mm, 1.1", C-mount | $899.00 | 5 in stock | View |
| LS-XR-1CM06-220 | 0.6x, WD 190 mm, 1.1", C-mount | $959.00 | 3 in stock | View |
| LS-XR-1CM052-110 | 0.52x, WD 110 mm, 1.1", C-mount | $1,019.00 | 4 in stock | View |
| LS-XR-1CM05-220 | 0.5x, WD 220 mm, 1.1", C-mount | $1,039.00 | 2 in stock | View |
| LS-XR-1CM04-178 | 0.4x, WD 178 mm, 1.1", C-mount | $1,159.00 | 3 in stock | View |
| LS-XR-1CM0345-178 | 0.345x, WD 178 mm, 1.1", C-mount | $1,259.00 | 5 in stock | View |
| LS-XR-1CM03-200 | 0.3x, WD 200 mm, 1.1", C-mount | $1,369.00 | 2 in stock | View |
| LS-XR-1CM0275-200 | 0.275x, WD 200 mm, 1.1", C-mount | $1,439.00 | 3 in stock | View |
| LS-XR-1CM025-230 | 0.25x, WD 230 mm, 1.1", C-mount | $1,529.00 | 4 in stock | View |
| LS-XR-1CM022-230 | 0.22x, WD 200 mm, 1.1", C-mount | $1,659.00 | 2 in stock | View |
| LS-XR-1CM02-250 | 0.2x, WD 250 mm, 1.1", C-mount | $1,769.00 | 3 in stock | View |
| LS-XR-1CM0172-230 | 0.172x, WD 230 mm, 1.1", C-mount | $1,969.00 | 2 in stock | View |
| LS-XR-1CM0153-250 | 0.153x, WD 250 mm, 1.1", C-mount | $2,149.00 | 4 in stock | View |
| LS-XR-1CM013-300 | 0.13x, WD 300 mm, 1.1", C-mount | $2,429.00 | 3 in stock | View |
| LS-XR-1CM011-320 | 0.11x, WD 320 mm, 1.1", C-mount | $2,769.00 | 2 in stock | View |
| LS-XR-1CM0078-410 | 0.078x, WD 410 mm, 1.1", C-mount | $3,679.00 | 3 in stock | View |
