Bi-telecentric lens for 1/2.5" cameras (VCM125 series)

The Bi-telecentric lens for 1/2.5" cameras (VCM125 series) is a range of 26 telecentric lenses from LumaSpec Vision, from $999.00. It comes in 26 sizes or versions. Every model below has its own page with full specifications, drawings and price.

Series datasheet (PDF)

Building a full system? Configure a camera, lens, light and controller that fit together →

The series at a glance

Sizes / versions	0.024x, WD 465 mm, 1/2.5", C-Mount, 0.027x, WD 438 mm, 1/2.5", C-Mount, 0.03x, WD 410 mm, 1/2.5", C-Mount, 0.033x, WD 372 mm, 1/2.5", C-mount, 0.038x, WD 330 mm, 1/2.5", C-mount, 0.042x, WD 318 mm, 1/2.5", C-Mount, 0.048x, WD 301 mm, 1/2.5", C-Mount, 0.053x, WD 288 mm, 1/2.5", C-Mount, 0.06x, WD 280 mm, 1/2.5", C-mount, 0.065x, WD 251 mm, 1/2.5", C-Mount, 0.077x, WD 254 mm, 1/2.5", C-Mount, 0.08x, WD 208 mm, 1/2.5", C-mount, 0.09x, WD 229 mm, 1/2.5", C-Mount, 0.1x, WD 178 mm, 1/2.5", C-Mount, 0.112x, WD 159 mm, 1/2.5", C-Mount, 0.113x, WD 187 mm, 1/2.5", C-Mount and 10 more
Mount	C-mount
Image circle	Up to 8 mm
Type	Bi-telecentric
Magnification	Under 0.1x, 0.1-0.3x
Working distance	65-110 mm, 110-200 mm, 200 mm +
Sensor format	1/2.5" and smaller

Features

Matrix design with extremely high imaging quality
Standard FOV from 26 to 240 mm, covering almost all industrial imaging applications
Compatible with all C-mount cameras from 1/2.5" to 1.1", and F/M-mount cameras from 4/3" to 59 mm
More than 168 standard types and hundreds of customised items
Excellent F-number, high telecentricity, extremely low distortion, very large DoF
Each lens comes with an imaging quality test report
Lens mount with conveniently adjustable flange distance (AL)
Matrix-design with extremely high imaging quality

Typical uses

Industrial imaging applications (standard FOV 26 to 240 mm)

All 26 models in the Bi-telecentric lens for 1/2.5" cameras (VCM125 series)

Model	Size	Price	Availability	Link
LS-VCM125-26-AL	0.277x, WD 72 mm, 1/2.5", C-Mount	$999.00	2 in stock	View
LS-VCM125-26	0.277x, WD 73 mm, 1/2.5", C-mount	$999.00	5 in stock	View
LS-VCM125-36-AL	0.199x, WD 111 mm, 1/2.5", C-Mount	$1,169.00	4 in stock	View
LS-VCM125-36	0.2x, WD 110 mm, 1/2.5", C-mount	$1,169.00	4 in stock	View
LS-VCM125-42-AL	0.172x, WD 119 mm, 1/2.5", C-Mount	$1,279.00	2 in stock	View
LS-VCM125-42	0.171x, WD 118 mm, 1/2.5", C-mount	$1,279.00	3 in stock	View
LS-VCM125-48-AL	0.15x, WD 128 mm, 1/2.5", C-Mount	$1,379.00	5 in stock	View
LS-VCM125-48S-AL	0.15x, WD 138 mm, 1/2.5", C-mount	$1,379.00	4 in stock	View
LS-VCM125-48	0.15x, WD 128 mm, 1/2.5", C-mount	$1,379.00	2 in stock	View
LS-VCM125-56-AL	0.129x, WD 138 mm, 1/2.5", C-Mount	$1,519.00	4 in stock	View
LS-VCM125-64-AL	0.113x, WD 187 mm, 1/2.5", C-Mount	$1,649.00	4 in stock	View
LS-VCM125-64P-AL	0.112x, WD 159 mm, 1/2.5", C-Mount	$1,649.00	2 in stock	View
LS-VCM125-72-AL	0.1x, WD 178 mm, 1/2.5", C-Mount	$1,789.00	3 in stock	View
LS-VCM125-80-AL	0.09x, WD 229 mm, 1/2.5", C-Mount	$1,929.00	2 in stock	View
LS-VCM125-90-AL	0.08x, WD 208 mm, 1/2.5", C-mount	$2,099.00	2 in stock	View
LS-VCM125-100-AL	0.077x, WD 254 mm, 1/2.5", C-Mount	$2,149.00	2 in stock	View
LS-VCM125-110-AL	0.065x, WD 251 mm, 1/2.5", C-Mount	$2,459.00	5 in stock	View
LS-VCM125-120-AL	0.06x, WD 280 mm, 1/2.5", C-mount	$2,609.00	5 in stock	View
LS-VCM125-136-AL	0.053x, WD 288 mm, 1/2.5", C-Mount	$2,889.00	4 in stock	View
LS-VCM125-150-AL	0.048x, WD 301 mm, 1/2.5", C-Mount	$3,129.00	4 in stock	View
LS-VCM125-170-AL	0.042x, WD 318 mm, 1/2.5", C-Mount	$3,439.00	4 in stock	View
LS-VCM125-190-AL	0.038x, WD 330 mm, 1/2.5", C-mount	$3,819.00	4 in stock	View
LS-VCM125-268-AL	0.027x, WD 438 mm, 1/2.5", C-Mount	$4,179.00	4 in stock	View
LS-VCM125-216-AL	0.033x, WD 372 mm, 1/2.5", C-mount	$4,259.00	5 in stock	View
LS-VCM125-300-AL	0.024x, WD 465 mm, 1/2.5", C-Mount	$4,629.00 quote	3 in stock	View
LS-VCM125-240-AL	0.03x, WD 410 mm, 1/2.5", C-Mount	$4,669.00	5 in stock	View
