Telecentric lenses · 25 models · from $629.00
Bi-telecentric lens for 2/3" sensor (XR-5M)
The Bi-telecentric lens for 2/3" sensor (XR-5M) is a range of 25 telecentric lenses from LumaSpec Vision, from $629.00. It comes in 20 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 0.063x, WD 320 mm, 2/3", C-mount, 0.095x, WD 250 mm, 2/3", C-mount, 0.12x, WD 250 mm, 2/3", C-mount, 0.14x, WD 200 mm, 2/3", C-mount, 0.15x, WD 238 mm, 2/3", C-mount, 0.178x, WD 158 mm, 2/3", C-mount, 0.2x, WD 178 mm, 2/3", C-mount, 0.22x, WD 200 mm, 2/3", C-mount, 0.265x, WD 178 mm, 2/3", C-mount, 0.3x, WD 110 mm, 2/3", C-mount, 0.3x, WD 178 mm, 2/3", C-mount, 0.5x, WD 110 mm, 2/3", C-mount, 0.5x, WD 178 mm, 2/3", C-mount, 0.5x, WD 275 mm, 2/3", C-mount, 0.78x, WD 290 mm, 2/3", C-mount, 0.8x, WD 110 mm, 2/3", C-mount and 4 more |
|---|---|
| Mount | C-mount |
| Image circle | Up to 8 mm |
| Type | Bi-telecentric |
| Coaxial light | Built-in coaxial light, No coaxial port |
| Magnification | Under 0.1x, 0.1-0.3x, 0.3-0.6x, 0.6-1x, 1-2x, 2x + |
| Working distance | 110-200 mm, 200 mm + |
| Sensor format | 2/3" |
Features
- Supports cameras with sensors up to 2/3" (dia. 11 mm)
- Excellent double-sided telecentric optical path, ultra-low distortion design
- Very large depth of field to image products at different heights
- High-precision alignment: measurement error < 0.3 pixel over the full field of view
- Lightweight, purpose-built structure performs stably during high-speed motion
All 25 models in the Bi-telecentric lens for 2/3" sensor (XR-5M)
| Model | Size | Price | Availability | Link |
|---|---|---|---|---|
| LS-XR-5M2-110 | 2x, WD 110 mm, 2/3", C-mount | $629.00 | 5 in stock | View |
| LS-XR-5M2-110C | WD 110 mm, 2/3", C-mount | $629.00 | 2 in stock | View |
| LS-XR-5M1.5-110 | 1.5x, WD 110 mm, 2/3", C-mount | $649.00 | 4 in stock | View |
| LS-XR-5M1.5-110C | 1.5x, WD 110 mm, 2/3", C-mount | $649.00 | 5 in stock | View |
| LS-XR-5M1-110 | 1x, WD 110 mm, 2/3", C-mount | $699.00 | 4 in stock | View |
| LS-XR-5M1-110C | 1x, WD 110 mm, 2/3", C-mount | $699.00 | 5 in stock | View |
| LS-XR-5M08-110 | 0.8x, WD 110 mm, 2/3", C-mount | $739.00 | 4 in stock | View |
| LS-XR-5M08-110C | 0.8x, WD 110 mm, 2/3", C-mount | $739.00 | 2 in stock | View |
| LS-XR-5M05-110 | 0.5x, WD 110 mm, 2/3", C-mount | $839.00 | 5 in stock | View |
| LS-XR-5M05-110C | 0.5x, WD 110 mm, 2/3", C-mount | $839.00 | 4 in stock | View |
| LS-XR-5M05-178 | 0.5x, WD 178 mm, 2/3", C-mount | $839.00 | 5 in stock | View |
| LS-XR-5M05-275 | 0.5x, WD 275 mm, 2/3", C-mount | $839.00 | 4 in stock | View |
| LS-XR-5M03-110 | 0.3x, WD 110 mm, 2/3", C-mount | $1,039.00 | 2 in stock | View |
| LS-XR-5M03-110C | 0.3x, WD 110 mm, 2/3", C-mount | $1,039.00 | 4 in stock | View |
| LS-XR-5M03-178 | 0.3x, WD 178 mm, 2/3", C-mount | $1,039.00 | 2 in stock | View |
| LS-XR-5M0265-178 | 0.265x, WD 178 mm, 2/3", C-mount | $1,099.00 | 2 in stock | View |
| LS-XR-5M022-200 | 0.22x, WD 200 mm, 2/3", C-mount | $1,209.00 | 4 in stock | View |
| LS-XR-5M02-178 | 0.2x, WD 178 mm, 2/3", C-mount | $1,279.00 | 4 in stock | View |
| LS-XR-5M0178-158 | 0.178x, WD 158 mm, 2/3", C-mount | $1,359.00 | 4 in stock | View |
| LS-XR-5M015-238-L90 | 0.15x, WD 238 mm, 2/3", C-mount | $1,519.00 | 2 in stock | View |
| LS-XR-5M014-200 | 0.14x, WD 200 mm, 2/3", C-mount | $1,579.00 | 5 in stock | View |
| LS-XR-5M012-250 | 0.12x, WD 250 mm, 2/3", C-mount | $1,759.00 | 3 in stock | View |
| LS-XR-5M0095-250 | 0.095x, WD 250 mm, 2/3", C-mount | $2,069.00 | 2 in stock | View |
| LS-XR-5M0078-290 | 0.78x, WD 290 mm, 2/3", C-mount | $2,399.00 | 4 in stock | View |
| LS-XR-5M0064-320 | 0.063x, WD 320 mm, 2/3", C-mount | $2,839.00 | 5 in stock | View |
