Bar lights · 32 models · from $69.00
Bar light (2BRD series)
The Bar light (2BRD series) is a range of 32 bar lights from LumaSpec Vision, from $69.00. It comes in 32 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 60 x 20 mm, 60 x 30 mm, 60 x 50 mm, 90 x 20 mm, 90 x 30 mm, 120 x 20 mm, 120 x 30 mm, 120 x 50 mm, 150 x 20 mm, 150 x 30 mm, 180 x 20 mm, 180 x 30 mm, 180 x 50 mm, 200 x 20 mm, 200 x 30 mm, 240 x 20 mm and 16 more |
|---|---|
| Colour | Red, Green, Blue, White |
| Type | Diffused, Standard |
| Voltage | 24 V |
| Connector | 3-pin flat |
Features
- Uniform light plate (diffuser)
- SMD LEDs, aluminium heat-sink housing
- 20 mm and 30 mm luminous widths, lengths 60-480 mm
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Long: 76mm, Wide: 26mm, High: 26mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:50000 hours for red light and 30000 hours for white light.
- Suitable for dimension measurement, defect detection, contour identification and transparent object impurity detection, etc.
Typical uses
- PCB substrate inspection, plastic container inspection
- Microscope illumination, general appearance inspection
- Chip and glass substrate scratch and stain detection
- LCD correction, font label detection
- Aluminium plate (pattern processing) inspection
All 32 models in the Bar light (2BRD series)
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-2BRD6020 | 60 x 20 mm | 1.8 W | $69.00 | 16 in stock | View | |
| LS-2BRD6030 | 60 x 30 mm | 2.6 W | $69.00 | 13 in stock | View | |
| LS-2BRD6050 | 60 x 50 mm | $69.00 | 5 in stock | View | ||
| LS-2BRD9020 | 90 x 20 mm | 2.2 W | $79.00 | 13 in stock | View | |
| LS-2BRD9030 | 90 x 30 mm | 3.8 W | $79.00 | 14 in stock | View | |
| LS-2BRD12020 | 120 x 20 mm | 2.8 W | $99.00 | 15 in stock | View | |
| LS-2BRD12030 | 120 x 30 mm | 4.4 W | $99.00 | 18 in stock | View | |
| LS-2BRD12050 | 120 x 50 mm | $99.00 | 3 in stock | View | ||
| LS-2BRD15020 | 150 x 20 mm | 3.6 W | $119.00 | 15 in stock | View | |
| LS-2BRD15030 | 150 x 30 mm | 5.5 W | $119.00 | 17 in stock | View | |
| LS-2BRD18020 | 180 x 20 mm | 4.2 W | $129.00 | 8 in stock | View | |
| LS-2BRD18030 | 180 x 30 mm | 6.6 W | $129.00 | 18 in stock | View | |
| LS-2BRD18050 | 180 x 50 mm | $129.00 | 5 in stock | View | ||
| LS-2BRD20020 | 200 x 20 mm | 5 W | $139.00 | 13 in stock | View | |
| LS-2BRD20030 | 200 x 30 mm | 7.5 W | $139.00 | 12 in stock | View | |
| LS-2BRD24020 | 240 x 20 mm | 5.6 W | $159.00 | 15 in stock | View | |
| LS-2BRD24030 | 240 x 30 mm | 8.8 W | $159.00 | 11 in stock | View | |
| LS-2BRD24050 | 240 x 50 mm | $159.00 | 3 in stock | View | ||
| LS-2BRD30020 | 300 x 20 mm | 7 W | $189.00 | 17 in stock | View | |
| LS-2BRD30030 | 300 x 30 mm | 11 W | $189.00 | 10 in stock | View | |
| LS-2BRD30050 | 300 x 50 mm | $189.00 | 4 in stock | View | ||
| LS-2BRD36020 | 360 x 20 mm | 8.4 W | $229.00 | 10 in stock | View | |
| LS-2BRD36030 | 360 x 30 mm | 13.2 W | $229.00 | 14 in stock | View | |
| LS-2BRD36050 | 360 x 50 mm | $229.00 | 4 in stock | View | ||
| LS-2BRD42020 | 420 x 20 mm | 9.8 W | $259.00 | 14 in stock | View | |
| LS-2BRD42030 | 420 x 30 mm | 15.4 W | $259.00 | 14 in stock | View | |
| LS-2BRD42050 | 420 x 50 mm | $259.00 | 2 in stock | View | ||
| LS-2BRD48020 | 480 x 20 mm | 11.2 W | $289.00 | 14 in stock | View | |
| LS-2BRD48030 | 480 x 30 mm | 17.6 W | $289.00 | 16 in stock | View | |
| LS-2BRD48050 | 480 x 50 mm | $289.00 | 4 in stock | View | ||
| LS-2BRD54050 | 540 x 50 mm | $319.00 | 2 in stock | View | ||
| LS-2BRD60050 | 600 x 50 mm | $349.00 | 2 in stock | View |
