Bar lights
600 x 50 mm Bar light (2BRD series) (LS-2BRD60050)
Model LS-2BRD60050
LED bar light with a uniform light (diffuser) plate, luminous sizes from 60 x 20 to 480 x 30 mm; suppresses reflections on the object surface so damage is clearly imaged.
Features
- Uniform light plate (diffuser)
- SMD LEDs, aluminium heat-sink housing
- 20 mm and 30 mm luminous widths, lengths 60-480 mm
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Long: 76mm, Wide: 26mm, High: 26mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:50000 hours for red light and 30000 hours for white light.
- Suitable for dimension measurement, defect detection, contour identification and transparent object impurity detection, etc.
Specifications
| Model | LS-2BRD60050 |
|---|---|
| Voltage | 24 V DC |
| LED type | SMD |
| Uniform light plate | yes |
| Operating environment (indoor) | temperature 0~40 °C, humidity 20~85% (non condensing) |
| Working life | white: 30000 hours, red: 30000 hours (the value varies according to the use environment) |
| Power tolerance | actual product power within ±10% of the table is the normal range |
| Quality service | one year product warranty, technical support |
| Luminous size(mm) | 600x50 |
| Color | Red |
| Color (2) | Blue/White/Green |
| Voltage(V) | 24V |
| Power(W) Red | 28 |
| Power(W) Blue/White/Green | 35 |
| Boundary dimension(mm) Long | 616 |
| Boundary dimension(mm) Wide | 58 |
| Boundary dimension(mm) High | 26 |
| LED Type SMD | √ |
| LED Type DIP | — |
| Uniformity diffuser | √ |
| Category | Bar light |
| Color (product page) | red/white/blue/green |
| Wavelength | red: 620-635nm; white: —; blue: 465-470nm; green: 525-530nm |
| Color-temperature | red: —; white: 5500-6500K; blue: —; green: — |
| Power | red: 28Wmax.; white: 35Wmax.; blue: 35Wmax.; green: — |
| Input Volt | DC24Vmax. |
| Cable length | 0.5m |
| Terminal Plug | Flat head 3PIN2 pin |
| Connector Definition | 1:positive(+)red; 2:leave empty; 3:negative(-)black. |
| Shell Material | Aluminum Alloy (Oxidative blackened surface) |
| Cooling | Naturalair cooling |
| Dimensions | L616mmxW58mmxH26mm |
| Shell Hardness Parameters | Static load 230N±10N,time 5 minutes contact area:diameter 30MM Energy level:5J elements: steel ball diameter 50MM,500g±25g |
| ElectricalIn Sulation Capacity | DC500V Insulation resistance>20 megohms |
| Pressure Resistance Requirements | AC1000V; 10mA/5S |
| Flammability Rating | IEC60707 |
| Operating Temperatureand Humidity | Temperature:0 to 50ºC,Humidity:20% to 85%RH(non-condensing) |
| Lifespan | Under our specified conditions of use,50000 hours for red light and 30000 hours for white light,the brightness is reduced to 50% of the factory value |
| Warranty Period | Under the conditions of use specified by the company,the warranty is two years from the date of shipment,and within two years,if there is a failure problem,it can be repaired or replaced free of charge |
| Value Added Services | One year free technical support |
| Brightness Controller (optional) | 1.Analog Controller 2.Digital Controller |
| Matingcable (optional) | 1.Light source extension cable 2.Connector adapter cable |
| Shipping weight | 1.25 kg |
Applications
- PCB substrate inspection, plastic container inspection
- Microscope illumination, general appearance inspection
- Chip and glass substrate scratch and stain detection
- LCD correction, font label detection
- Aluminium plate (pattern processing) inspection
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Bar light (2BRD series) series
| Model | Size | Power | Colours | Price | Availability | |
|---|---|---|---|---|---|---|
| LS-2BRD12050 | 120 x 50 mm | $99.00 | 3 in stock | View | ||
| LS-2BRD15020 | 150 x 20 mm | 3.6 W | $119.00 | 15 in stock | View | |
| LS-2BRD15030 | 150 x 30 mm | 5.5 W | $119.00 | 17 in stock | View | |
| LS-2BRD18020 | 180 x 20 mm | 4.2 W | $129.00 | 8 in stock | View | |
| LS-2BRD18030 | 180 x 30 mm | 6.6 W | $129.00 | 18 in stock | View | |
| LS-2BRD18050 | 180 x 50 mm | $129.00 | 5 in stock | View | ||
| LS-2BRD20020 | 200 x 20 mm | 5 W | $139.00 | 13 in stock | View | |
| LS-2BRD20030 | 200 x 30 mm | 7.5 W | $139.00 | 12 in stock | View | |
| LS-2BRD24020 | 240 x 20 mm | 5.6 W | $159.00 | 15 in stock | View | |
| LS-2BRD24030 | 240 x 30 mm | 8.8 W | $159.00 | 11 in stock | View | |
| LS-2BRD24050 | 240 x 50 mm | $159.00 | 3 in stock | View | ||
| LS-2BRD30020 | 300 x 20 mm | 7 W | $189.00 | 17 in stock | View | |
| LS-2BRD30030 | 300 x 30 mm | 11 W | $189.00 | 10 in stock | View | |
| LS-2BRD30050 | 300 x 50 mm | $189.00 | 4 in stock | View | ||
| LS-2BRD36020 | 360 x 20 mm | 8.4 W | $229.00 | 10 in stock | View | |
| LS-2BRD36030 | 360 x 30 mm | 13.2 W | $229.00 | 14 in stock | View | |
| LS-2BRD36050 | 360 x 50 mm | $229.00 | 4 in stock | View | ||
| LS-2BRD42020 | 420 x 20 mm | 9.8 W | $259.00 | 14 in stock | View | |
| LS-2BRD42030 | 420 x 30 mm | 15.4 W | $259.00 | 14 in stock | View | |
| LS-2BRD42050 | 420 x 50 mm | $259.00 | 2 in stock | View | ||
| LS-2BRD48020 | 480 x 20 mm | 11.2 W | $289.00 | 14 in stock | View | |
| LS-2BRD48030 | 480 x 30 mm | 17.6 W | $289.00 | 16 in stock | View | |
| LS-2BRD48050 | 480 x 50 mm | $289.00 | 4 in stock | View | ||
| LS-2BRD54050 | 540 x 50 mm | $319.00 | 2 in stock | View |
