Bar lights · 26 models · from $49.00
Strip light, 17 series (LS-L17)
The Strip light, 17 series (LS-L17) is a range of 26 bar lights from LumaSpec Vision, from $49.00. It comes in 25 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 25.2 mm, 50.6 mm, 70.2 mm, 75.6 mm, 92.6 mm, 100.8 mm, 126 mm, 151.2 mm, 176.4 mm, 201.6 mm, 226.8 mm, 252 mm, 277.2 mm, 302.4 mm, 378 mm, 403.2 mm and 9 more |
|---|---|
| Colour | Red, Green, Blue, White, Infrared, UV |
| Type | Strip / combination |
| Voltage | 24 V |
Features
- First choice for large-area lighting, high cost performance
- Surface-mount LEDs and special optical lenses, concentrated divergence angle, high light efficiency
- Stable mass production
- Size can be customized according to different needs
Typical uses
- Metal surface inspection
- PCB substrate inspection, electronic component inspection, appearance defect inspection
- Printed material character recognition, mobile phone case positioning, PCB component presence/absence detection
All 26 models in the Strip light, 17 series (LS-L17)
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-L2517 | 25.2 mm | 1.1 W | $49.00 | 19 in stock | View | |
| LS-L5017 | 50.6 mm | 1.73 W | $59.00 | 22 in stock | View | |
| LS-L7017 | 70.2 mm | 2.6 W | $69.00 | 23 in stock | View | |
| LS-L7517 | 75.6 mm | 2.8 W | $79.00 | 23 in stock | View | |
| LS-L9217 | 92.6 mm | 3.2 W | $89.00 | 26 in stock | View | |
| LS-L10017 | 100.8 mm | 3.46 W | $89.00 | 22 in stock | View | |
| LS-L12517 | 126 mm | 4.6 W | $99.00 | 17 in stock | View | |
| LS-L13517 | 4.8 W | $109.00 | 21 in stock | View | ||
| LS-L15017 | 151.2 mm | 5.18 W | $119.00 | 23 in stock | View | |
| LS-L17517 | 176.4 mm | 6.5 W | $129.00 | 19 in stock | View | |
| LS-L20017 | 201.6 mm | 6.91 W | $139.00 | 25 in stock | View | |
| LS-L22517 | 226.8 mm | 7.4 W | $159.00 | 22 in stock | View | |
| LS-L25017 | 252 mm | 7.6 W | $169.00 | 23 in stock | View | |
| LS-L27517 | 277.2 mm | 8.4 W | $179.00 | 23 in stock | View | |
| LS-L30017 | 302.4 mm | 8.64 W | $199.00 | 22 in stock | View | |
| LS-L37517 | 378 mm | 13 W | $229.00 | 17 in stock | View | |
| LS-L40017 | 403.2 mm | 11.52 W | $249.00 | 23 in stock | View | |
| LS-L45017 | 453.6 mm | 12.9 W | $269.00 | 24 in stock | View | |
| LS-L47517 | 478.8 mm | 13.6 W | $289.00 | 22 in stock | View | |
| LS-L50017 | 504 mm | 14.4 W | $299.00 | 19 in stock | View | |
| LS-L52517 | 529.2 mm | 15 W | $309.00 | 19 in stock | View | |
| LS-L55017 | 554.4 mm | 15.8 W | $329.00 | 28 in stock | View | |
| LS-L57517 | 579.6 mm | 16.5 W | $339.00 | 21 in stock | View | |
| LS-L60017 | 604.8 mm | 22.46 W | $349.00 | 23 in stock | View | |
| LS-L80017 | 806.4 mm | 27.65 W | $459.00 | 22 in stock | View | |
| LS-L100017 | 1008 mm | 34.56 W | $569.00 | 19 in stock | View |
