Bar lights · 5 models · from $69.00
Infrared light (IR)
The Infrared light (IR) is a range of 5 bar lights from LumaSpec Vision, from $69.00. It comes in 5 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 60 x 16 mm, 75 x 30 mm, 90 x 16 mm, 125 x 30 mm, 180 x 16 mm |
|---|---|
| Colour | Infrared |
| Type | Standard |
| Voltage | 24 V |
| Wavelength | 940 nm |
Features
- Strong penetration, wavelength optional: 850/940 nm
- Use with high sensitive CCD of near infrared field
- Use with infrared glass filter, adapts to strong ambient light
Typical uses
- Monitoring
- Packing (through the plastic packing)
- Foreign matter inspection in wine bottles
- Electronic, semiconductor inspection
- Imaging example: lingerie buckle inspection through clothing (LS-2FT100100-IR)
All 5 models in the Infrared light (IR)
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-2BR6016-IR | 60 x 16 mm | 1 W | $69.00 | 3 in stock | View | |
| LS-2BR9016-IR | 90 x 16 mm | 1.4 W | $79.00 | 3 in stock | View | |
| LS-2BR7530-IR | 75 x 30 mm | 2.2 W | $79.00 | 5 in stock | View | |
| LS-2BR12530-IR | 125 x 30 mm | 3.6 W | $99.00 | 2 in stock | View | |
| LS-2BR18016-IR | 180 x 16 mm | 2.9 W | $129.00 | 5 in stock | View |
