0.051× telecentric lens, 2/3", C-mount (LS-TCL-0253)

Model LS-TCL-0253

Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 526.9 mm; depth of field 159.2 mm.

Datasheet (PDF) - LS-TCL-0253 3D model (STEP) - LS-TCL-0253

Specifications

Model	LS-TCL-0253
Magnification	0.051×
Working distance	526.9 mm
Sensor format	2/3"
Mount	C-mount
Depth of field	159.2 mm
Dimensions approximate	630.3 x 260 x 260 mm
Distortion maximum (%)	< 0.1
Distortion typical (%)	< 0.04
Filter thread	No Filter Threads
FOV @ 1/1.8″	139.80 x 104.51 mm
Fov @ 1/2.0″	125.49 x 94.12 mm
Fov @ 1/2.5″	111.76 x 83.92 mm
FOV @ 1/2″	125.49 x 94.12 mm
Fov @ 1/3.0″	94.12 x 70.59 mm
FOV @ 2/3″	166.67 x 139.02 mm
Front diameter	260 mm
Image circle	11 mm
Lens type	Telecentric
Operating temperature range	0 to 40°C
Resolution (pixel size)	100 μm
Storage temperature range	0 to 50°C
Telecentricity maximum	0.08°
Telecentricity typical	< 0.05°
Working ƒ/n	f/8
Weight	9916 Grams
