Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.072× telecentric lens, 2/3", C-mount (LS-TCL-0250)
Model LS-TCL-0250
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 334.5 mm; depth of field 79.9 mm.
Specifications
| Model | LS-TCL-0250 |
|---|---|
| Magnification | 0.072× |
| Working distance | 334.5 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Depth of field | 79.9 mm |
| Dimensions approximate | 422.4 x 180 x 180 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.04 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 99.03 x 74.03 mm |
| Fov @ 1/2.0″ | 88.89 x 66.67 mm |
| Fov @ 1/2.5″ | 79.17 x 59.44 mm |
| Fov @ 1/2″ | 88.89 x 66.67 mm |
| Fov @ 1/3.0″ | 66.67 x 50.00 mm |
| Fov @ 2/3″ | 118.06 x 98.47 mm |
| Front diameter | 180 mm |
| Image circle | 11 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 70 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.08° |
| Telecentricity typical | < 0.07° |
| Working ƒ/n | f/8 |
| Weight | 4720 Grams |
