Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.079× telecentric lens, 2/3", C-mount (LS-TCL-0249)
Model LS-TCL-0249
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 334.5 mm; depth of field 66.3 mm.
Specifications
| Model | LS-TCL-0249 |
|---|---|
| Magnification | 0.079× |
| Working distance | 334.5 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Depth of field | 66.3 mm |
| Dimensions approximate | 430.4 x 180 x 180 mm |
| Distortion maximum (%) | < 0.07 |
| Distortion typical (%) | < 0.03 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 90.25 x 67.47 mm |
| Fov @ 1/2.0″ | 81.01 x 60.76 mm |
| Fov @ 1/2.5″ | 72.15 x 54.18 mm |
| Fov @ 1/2″ | 81.01 x 60.76 mm |
| Fov @ 1/3.0″ | 60.76 x 45.57 mm |
| Fov @ 2/3″ | 107.59 x 89.75 mm |
| Front diameter | 180 mm |
| Image circle | 11 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 64 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.08° |
| Telecentricity typical | < 0.06° |
| Working ƒ/n | f/8 |
| Weight | 4734 Grams |
