3× telecentric lens, 35mm Full Frame, F-mount (LS-TCL-0184)

Model LS-TCL-0184

Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 57.8 mm; depth of field 0.2 mm.

Datasheet (PDF) - LS-TCL-0184 3D model (STEP) - LS-TCL-0184

Specifications

Model	LS-TCL-0184
Magnification	3×
Working distance	57.8 mm
Sensor format	35mm Full Frame
Mount	F-mount
Depth of field	0.2 mm
Aps-c IMX342	7.45 x 5.59 mm
CHR70M	10.33 x 7.33 mm
CMV50000	12.14 x 9.21 mm
Dimensions approximate	378.7 x 37. x 37.7 mm
Distortion maximum (%)	< 0.05
Distortion typical (%)	< 0.03
Filter thread	No Filter Threads
Fov @ full frame	12 x 8 mm
Front diameter	37.7 mm
Image circle	43.3 mm
Lens type	Telecentric
Line 8k-5µm	13.6 mm
Operating temperature range	0 to 40°C
Resolution (pixel size)	4 μm
Storage temperature range	0 to 50°C
Telecentricity maximum	0.05°
Telecentricity typical	< 0.03°
Working ƒ/n	f/18
Weight	869 Grams
