Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.561× telecentric lens, 35mm Full Frame, M58-Mount (LS-TCL-0200)
Model LS-TCL-0200
0.561× telecentric lens, 35mm Full Frame, M58-Mount. Working distance 170.6 mm. Depth of field 4.2 mm.
Specifications
| Model | LS-TCL-0200 |
|---|---|
| APS-C IMX342 | 39.86 x 29.89 mm |
| CHR70M | 55.26 x 39.2 mm |
| CMV50000 | 64.94 x 49.23 mm |
| Depth Of Field | 4.2 mm |
| Distortion Maximum (%) | < 0.15 |
| Distortion Typical (%) | < 0.06 |
| Filter Thread | No Filter Threads |
| FoV @ Full Frame | 64.17 x 42.78 mm |
| Front Diameter | 100 mm |
| Image Circle Diameter | 43.3 mm |
| Imager Format | 35mm Full Frame |
| Lens Type | Telecentric |
| Line 8k-5µm | 72.73 mm |
| Magnification | 0.561× |
| Mount | M58-Mount |
| Resolution (Pixel Size) | 18 μm |
| Telecentricity Maximum | 0.08° |
| Telecentricity Typical | < 0.04° |
| Working Distance | 170.6 mm |
| Working ƒ/N | f/16 |
