Ring lights · 12 models · from $89.00
Flash light source
The Flash light source is a range of 12 ring lights from LumaSpec Vision, from $89.00. It comes in 11 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 24 x 24 mm, 26 x 27 mm, 32 x 25 mm, 35 x 22 mm, 38 x 39 mm, 62 mm, 66 mm, 70 x 22 mm, 90 x 32 mm, 100 mm, 116 mm |
|---|---|
| Colour | Red, Blue, White |
| Type | Strobe |
| Connector | XS10-3T |
| Voltage | 24 V |
Features
- Improves brightness instantaneously; max brightness of some lights can reach ten million lux
- Suitable for high-speed flying applications
- Used for stroboscopic operation: lower heating, longer life
- Various series can be customised to different application requirements
Typical uses
- Steel plate positioning (exposure 4 us)
- Line appearance inspection (exposure 5 us)
- Bottle cap defect inspection (exposure 4 us)
- Inspection items with very high speed requirements; strobe light types include bar, coaxial, dome and ring shadowless lights
All 12 models in the Flash light source
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-2SBS4728 | 35 x 22 mm | 768 W | $89.00 | 5 in stock | View | |
| LS-SCOSC24 | 24 x 24 mm | 312 W | $89.00 | 2 in stock | View | |
| LS-SCOSC3225 | 32 x 25 mm | 456 W | $89.00 | 2 in stock | View | |
| LS-SCOS26 | 26 x 27 mm | 312 W | $109.00 | 3 in stock | View | |
| LS-SCOS40 | 38 x 39 mm | 1200 W | $119.00 | 2 in stock | View | |
| LS-SRS7390 | 768 W | $129.00 | 5 in stock | View | ||
| LS-2SBS8228 | 70 x 22 mm | 1200 W | $139.00 | 7 in stock | View | |
| LS-SDS84 | 62 mm | 600 W | $139.00 | 5 in stock | View | |
| LS-2SBS10238 | 90 x 32 mm | 912 W | $169.00 | 7 in stock | View | |
| LS-SDS116 | 66 mm | 1056 W | $179.00 | 2 in stock | View | |
| LS-SHRS116 | 100 mm | 1200 W | $179.00 | 3 in stock | View | |
| LS-SDS175 | 116 mm | 1200 W | $259.00 | 3 in stock | View |
