Machine vision lenses · 5 models · from $309.00
Macro lens, 1.1" 12MP
The Macro lens, 1.1" 12MP is a range of 5 machine vision lenses from LumaSpec Vision, from $309.00. It comes in 5 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 16 mm, 1.1", C-Mount, 25 mm, 1.1", C-Mount, 35 mm, 1.1", C-Mount, 50 mm, 1.1", C-Mount, 75 mm, 1.1", C-Mount |
|---|---|
| Mount | C-mount |
| Resolution | 12 MP |
| Image circle | 16-22 mm |
| Focal length | 12-25 mm, 25-50 mm, 50-100 mm |
| Type | Macro / special |
| Sensor format | 1.1" - 1.2" |
Features
- High resolution up to 12MP
- Designed for precise imaging with limited space, WD from 52mm to 546mm
- Large image circle, suitable for IMX253LLR (1.1" 12MP)
- EFL range from 16mm to 75mm
- Magnification range from 0.03x-0.8x
- Ultra-low distortion (<0.05%)
- High contrast, low distortion
Typical uses
- Industrial: blemish / stain - inspect steel plate for defects and blemishes
- Electronic component: yes or no / identify - check the number of tiny chips and poor imprint
- Electronic component: blemish / stain - detecting camera defects
- Electronic equipment: yes or no / identify - detect poor binding and lead breakage of motor wires
All 5 models in the Macro lens, 1.1" 12MP
| Model | Size | Price | Availability | Link |
|---|---|---|---|---|
| LS-ML1610A | 16 mm, 1.1", C-Mount | $309.00 | 5 in stock | View |
| LS-ML2510A | 25 mm, 1.1", C-Mount | $319.00 | 2 in stock | View |
| LS-ML3510A | 35 mm, 1.1", C-Mount | $339.00 | 2 in stock | View |
| LS-ML5010A | 50 mm, 1.1", C-Mount | $359.00 | 3 in stock | View |
| LS-ML7510A | 75 mm, 1.1", C-Mount | $389.00 | 5 in stock | View |
