Light controllers · 6 models · from $239.00
High power constant current controller (DPA)
The High power constant current controller (DPA) is a range of 6 light controllers from LumaSpec Vision, from $239.00. It comes in 6 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 1 ch, 1200 W, 1 ch, 200 W, 1 ch, 400 W, 1 ch, 500 W, 1 ch, 800 W, 2 ch, 400 W |
|---|---|
| Output | Constant current |
| Channels | 1 channel, 2 channels |
| Control | Analog |
| Feature | Constant current |
Features
- Each channel controlled independently with high precision
- Digital display, button control
- Communicates with PC by RS232 (and LAN)
- Trigger, fast response, high reliability
- Power off saving function
- Cooling fan
- AS16 aviation connector light interface
- Trigger delay T1 <= 80us, T3 <= 80us
All 6 models in the High power constant current controller (DPA)
| Model | Size | Power | Price | Availability | Link |
|---|---|---|---|---|---|
| LS-DPA24200-1S | 1 ch, 200 W | 200 W | $239.00 | 4 in stock | View |
| LS-DPA24400-1S | 1 ch, 400 W | 400 W | $329.00 | 2 in stock | View |
| LS-DPA24400-2S | 2 ch, 400 W | 400 W | $359.00 | 3 in stock | View |
| LS-DPA48600-1S | 1 ch, 500 W | 500 W | $369.00 | 5 in stock | View |
| LS-DPA481000-1S | 1 ch, 800 W | 800 W | $499.00 | 3 in stock | View |
| LS-DPA481200-1S | 1 ch, 1200 W | 1200 W | $679.00 | 5 in stock | View |
