High power constant current controller (DPA), 1 ch, 400 W (LS-DPA24400-1S)
Model LS-DPA24400-1S
High power constant current controller: each channel controlled independently with high precision, digital display and button control, RS232/LAN communication with PC, trigger input and power-off saving.
Features
- Each channel controlled independently with high precision
- Digital display, button control
- Communicates with PC by RS232 (and LAN)
- Trigger, fast response, high reliability
- Power off saving function
- Cooling fan
- AS16 aviation connector light interface
- Trigger delay T1 <= 80us, T3 <= 80us
- MANU (normal on) / REMO (normal closed) modes via TS switch
Specifications
| Model | LS-DPA24400-1S |
|---|---|
| Input frequency | 43-67Hz |
| Communication | RS232, LAN |
| Luminance control method | manual adjust by button, PC remote adjustment |
| Luminance control mode | Constant-current |
| Luminance control level | 256 level |
| Storage function | luminance kept when power off |
| External trigger voltage | high level 5-24V |
| Fan supply output | 24V 2A |
| Baud rate | 9600bps |
| Channels | 1 |
| Single channel output current | 0-16A |
| One way max. output power | 400W |
| Total output power | 400W |
| External trigger support | Y |
| Input voltage | AC 100-240V |
| Shipping weight | 2.85 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the High power constant current controller (DPA) series
| Model | Size | Power | Price | Availability | |
|---|---|---|---|---|---|
| LS-DPA24200-1S | 1 ch, 200 W | 200 W | $239.00 | 4 in stock | View |
| LS-DPA24400-2S | 2 ch, 400 W | 400 W | $359.00 | 3 in stock | View |
| LS-DPA48600-1S | 1 ch, 500 W | 500 W | $369.00 | 5 in stock | View |
| LS-DPA481000-1S | 1 ch, 800 W | 800 W | $499.00 | 3 in stock | View |
| LS-DPA481200-1S | 1 ch, 1200 W | 1200 W | $679.00 | 5 in stock | View |
