Light controllers · 6 models · from $219.00
485 type digital controller
The 485 type digital controller is a range of 6 light controllers from LumaSpec Vision, from $219.00. It comes in 6 sizes or versions. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Sizes / versions | 2 ch, 120 W, 2 ch, 200 W, 2 ch, 65 W, 4 ch, 4 ch, 120 W, 4 ch, 65 W |
|---|---|
| Output | Constant voltage 24 V |
| Channels | 2 channels, 4 channels |
| Control | Digital |
Features
- Support RS232/RS485 communication
- External power supply up to 24V
- Low trigger response time
- Support external trigger mode
- Support millisecond strobe and microsecond strobe
- Brightness and mode can be set manually
- 5~24V trigger, adaptable to high and low level trigger modes
- Small size, easy to install, screw mounting or C45 rail mounting
All 6 models in the 485 type digital controller
| Model | Size | Power | Price | Availability | Link |
|---|---|---|---|---|---|
| LS-DV65-N04C-24025-2 | 2 ch, 65 W | 65 W | $219.00 | 3 in stock | View |
| LS-DV120-N04C-24040-2 | 2 ch, 120 W | 120 W | $239.00 | 3 in stock | View |
| LS-DV200-N04C-24040-2 | 2 ch, 200 W | 200 W | $279.00 | 2 in stock | View |
| LS-DV65-N04C-24025-4 | 4 ch, 65 W | 65 W | $279.00 | 5 in stock | View |
| LS-DV-N04C-24040-4 | 4 ch | $299.00 | 5 in stock | View | |
| LS-DV120-N04C-24040-4 | 4 ch, 120 W | 120 W | $309.00 | 3 in stock | View |
