50 mm, 1.1", 20 MP, C-mount Machine Vision Lens (LS-FFL-0561)
  • 50 mm, 1.1", 20 MP, C-mount Machine Vision Lens (LS-FFL-0561)
  • LS-FFL-0561 dimensions (mm)

Machine vision lenses

50 mm, 1.1", 20 MP, C-mount Machine Vision Lens (LS-FFL-0561)

Model LS-FFL-0561

  • Focal length50 mm
  • Magnification0.01x ~ 0.179x
  • MountC-mount
  • Sensor1.1"
  • ApertureF2.8 manual iris
  • Resolution20 MP
$739.00

Ships in 2-3 weeks

0.34 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

50 mm, 1.1", 20 MP, C-mount Machine Vision Lens (LS-FFL-0561)LS-FFL-0561

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

50 mm, 1.1", 20 MP, C-mount Machine Vision Lens. 50 mm 1.1" 20 MP C-mount machine vision lens with <0.04% distortion and 0.01x-0.179x magnification; covers 1.1" down to 1/2" sensors. At a glance: magnification 0.01x ~ 0.179x; focal length 50 mm; format 1.1"; resolution 20 MP; aperture F2.8 manual iris.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-0561
Format1.1"
Angle of view (1.1", DxHxV)20 x 16 x 12 deg
Angle of view (1", DxHxV)18.2 x 15 x 11 deg
Angle of view (2/3", DxHxV)13 x 10.1 x 7.5 deg

Optics

Focal length50 mm
ApertureF2.8 manual iris
Back focal length21.1 mm
M.O.D.0.3 m
Distortion<0.04%
Filter threadM35.5 x P0.5
Magnification0.01x ~ 0.179x

Sensor and imaging

Resolution20 MP

Light

Illumination45%

Mechanical

Sizedia. 38 x 53.9
MountC
Weight175 g
Optical total length71.4 mm
Shipping weight (estimated)0.34 kg
