Bar lights
High brightness bar light (LS-BAR-S71)
- 5 models
- from $159.00
- Series LS-BAR-S71
The High brightness bar light (LS-BAR-S71) is a range of 5 bar lights from LumaSpec Vision, from $159.00. It comes in 5 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 48 x 18 mm, 88 x 18 mm, 188 x 18 mm, 288 x 18 mm, 388 x 18 mm
- Colour
- Red, Green, Blue, White
- Type
- Linear / high intensity
- Voltage
- 24 V
Features
- The brightness is three times more than standard bar lights
- Adopts high-power LEDs to realize lighting over long distance
Typical uses
- Suitable for all applications of bar light
- Various character recognition
- Various appearance inspection
- Various damage and defect inspection
- QR codes, one-dimension bar code reading
- Part inspection on substrates
All 5 models in the High brightness bar light (LS-BAR-S71)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BAR-0630 | 48 x 18 mm | 48 x 18 | 60 | 5.6 | $159.00 | View |
| LS-BAR-0631 | 88 x 18 mm | 88 x 18 | 100 | 12 | $199.00 | View |
| LS-BAR-0632 | 188 x 18 mm | 188 x 18 | 200 | 23 | $279.00 | View |
| LS-BAR-0633 | 288 x 18 mm | 288 x 18 | 300 | 40 | $319.00 | View |
| LS-BAR-0634 | 388 x 18 mm | 388 x 18 | 400 | 45 | $449.00 | View |
