Bar lights
Strip light, LS-BAR-S90 series
- 26 models
- from $89.00
- Series LS-BAR-S90
The Strip light, LS-BAR-S90 series is a range of 26 bar lights from LumaSpec Vision, from $89.00. It comes in 25 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 25.2 mm, 50.6 mm, 70.2 mm, 75.6 mm, 92.6 mm, 100.8 mm, 126 mm, 151.2 mm, 176.4 mm, 201.6 mm, 226.8 mm, 252 mm, 277.2 mm, 302.4 mm, 378 mm, 403.2 mm and 9 more
- Colour
- Red, Green, Blue, White, Infrared, UV
- Type
- Strip / combination
- Voltage
- 24 V
Features
- First choice for large-area lighting, high cost performance
- Surface-mount LEDs and special optical lenses, concentrated divergence angle, high light efficiency
- Stable mass production
- Size can be customized according to different needs
Typical uses
- Metal surface inspection
- PCB substrate inspection, electronic component inspection, appearance defect inspection
- Printed material character recognition, mobile phone case positioning, PCB component presence/absence detection
All 26 models in the Strip light, LS-BAR-S90 series
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-BAR-0931 | 25.2 mm | 40.2 | 1 | 1.1 | $89.00 | View |
| LS-BAR-0932 | 50.6 mm | 65.4 | 1.38 | 1.73 | $159.00 | View |
| LS-BAR-0933 | 70.2 mm | 85 | 2.1 | 2.6 | $179.00 | View |
| LS-BAR-0934 | 75.6 mm | 90.6 | 2.6 | 2.8 | $189.00 | View |
| LS-BAR-0938 | 146 | 3.2 | 4.8 | $189.00 | View | |
| LS-BAR-0935 | 92.6 mm | 107.4 | 2.7 | 3.2 | $209.00 | View |
| LS-BAR-0936 | 100.8 mm | 115.8 | 2.76 | 3.46 | $219.00 | View |
| LS-BAR-0937 | 126 mm | 141 | 3.1 | 4.6 | $249.00 | View |
| LS-BAR-0939 | 151.2 mm | 166.2 | 4.15 | 5.18 | $259.00 | View |
| LS-BAR-0940 | 176.4 mm | 191.4 | 6.5 | 6.5 | $279.00 | View |
| LS-BAR-0943 | 252 mm | 267 | 5.76 | 7.6 | $299.00 | View |
| LS-BAR-0941 | 201.6 mm | 216.6 | 5.53 | 6.91 | $309.00 | View |
| LS-BAR-0944 | 277.2 mm | 292.2 | 8 | 8.4 | $309.00 | View |
| LS-BAR-0945 | 302.4 mm | 317.4 | 6.91 | 8.64 | $329.00 | View |
| LS-BAR-0942 | 226.8 mm | 241.8 | 7.3 | 7.4 | $359.00 | View |
| LS-BAR-0946 | 378 mm | 393 | 12 | 13 | $399.00 | View |
| LS-BAR-0947 | 403.2 mm | 418.2 | 9.22 | 11.52 | $519.00 | View |
| LS-BAR-0949 | 478.8 mm | 493.8 | 13.3 | 13.6 | $519.00 | View |
| LS-BAR-0950 | 504 mm | 519 | 9.22 | 14.4 | $569.00 | View |
| LS-BAR-0948 | 453.6 mm | 468.6 | 12.3 | 12.9 | $579.00 | View |
| LS-BAR-0951 | 529.2 mm | 544.2 | 14.6 | 15 | $579.00 | View |
| LS-BAR-0952 | 554.4 mm | 569.4 | 15.3 | 15.8 | $579.00 | View |
| LS-BAR-0953 | 579.6 mm | 594.6 | 16 | 16.5 | $579.00 | View |
| LS-BAR-0954 | 604.8 mm | 619.8 | 17.97 | 22.46 | $629.00 | View |
| LS-BAR-0955 | 806.4 mm | 821.4 | 22.12 | 27.65 | $929.00 | View |
| LS-BAR-0956 | 1008 mm | 1023 | 27.65 | 34.56 | $1,249.00 | View |
