Representative photo of this series
Bar lights
48 x 18 mm High brightness bar light (LS-BAR-0630)
Model LS-BAR-0630
- ColourRed, Green, Blue, White
- Emitting area48 x 18 mm
- TypeLinear / high intensity
- Voltage24 V
$159.00
Ships in 2-3 weeks
0.3 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
High-brightness bar light, three times brighter than standard bar lights. High-power LEDs allow lighting over long distances.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-BAR-0630 |
|---|---|
| Optional accessories | Extension cable, diffuse plate |
| Service life | Red: 60000 h continuous at 25 °C and 50% illumination until 50% decrement; white: 30000 h under the same conditions |
| Lamp bead rows | 1 |
| L (mm) | 60 |
| W (mm) | 26 |
| H (mm) | 58 |
Interfaces and I/O
| Cable length | 500 mm (drawings) |
|---|
Light
| Wavelength red | 620-630 nm |
|---|---|
| Wavelength green | 520-530 nm |
| Wavelength blue | 465-475 nm |
| Colour temperature white | 6000-6500 K |
| Wavelength IR | 850-940 nm |
| Wavelength UV | 365-405 nm |
| Emitting area (mm) | 48 x 18 |
Environment and compliance
| Storage temperature | -20 to 60 °C |
|---|---|
| Operating temperature | 0 to 40 °C |
| Humidity | 20-85 %RH (non-condensing) |
Electrical
| Controller | LS-CTL-S69 series, LS-CTL-S28 series, LS-CTL-S125 series (the selected controller should match the power of the light source) |
|---|---|
| Power R (W) | 5.6 |
| Power G/B/W (W) | 5.6 |
| Recommended controller | LS-CTL-S69, LS-CTL-S28, LS-CTL-S125 |
| Supply voltage (derived) | 24 V DC, derived from the 24 V output of its recommended controllers LS-CTL-S69, LS-CTL-S28 |
Mechanical
| Mounting | 2 x 4-M3, depth 4 (drawings) |
|---|---|
| Shipping weight | 0.30 kg |
Other models in the High brightness bar light (LS-BAR-S71) series
See all 5 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-BAR-0631 | 88 x 18 mm | $199.00 | Ships in 2-3 weeks | View |
| LS-BAR-0632 | 188 x 18 mm | $279.00 | Ships in 2-3 weeks | View |
| LS-BAR-0633 | 288 x 18 mm | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-0634 | 388 x 18 mm | $449.00 | Ships in 2-3 weeks | View |
