Hikrobot MV-CL082-91F2M 8K7 XoF dual fiber port mono line scan camera
Model MV-CL082-91F2MHikrobot
- Resolution8192×2
- SensorCMOS
- Interface2LC fiber port
- Speed200 kHz(1-Line), 100 kHz(2-TDI)
- Lens mountM72
- Mono / colourMono
$1,919.00
Quoted price: add to quote for lead time and volume pricing.
End of life soon: the maker is phasing this model out, so stock is limited. Ask us for availability or the successor model.
Ships in 2-3 weeks
0.94 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CL082-91F2M 8K7 XoF dual fiber port mono line scan camera. Rich ISP image processing, including manual gamma correction, flat-field correction, LUT and black level adjustment Dual-channel XoF fiber ports for high-bandwidth transmission
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CL082-91F2M |
|---|---|
| Brand | Hikrobot |
| Image mode | 1-Line supported, 2-TDI |
| Compatibility | XoFLink, GenlCam |
| Transmission mode | 1Link, 2Link |
Sensor and imaging
| Sensor type | CMOS |
|---|---|
| Pixel size | 7 μm |
| Resolution | 8192×2 |
| Max. line rate | 200 kHz(1-Line), 100 kHz(2-TDI) |
| Dynamic range | 63.4 dB |
| SNR | 40.8 dB |
| Gain | 1.0 × |
| Exposure time | 3 μs ~ 10 ms |
| Exposure mode | Off/ Once/ Continuous exposure mode, and supports trigger-width exposure |
| Mono/color | Mono |
| Pixel format | Mono 8/10/12 |
| Binning | 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4 |
| Reverse image | Supports horizontal reverse image output |
Interfaces and I/O
| Data interface | 2LC fiber port |
|---|---|
| Digital I/O | 12-pin P10 connector provides power and I/O: Configurable input/output × 4 (Line 0/1/3/4), and single-ended/differential is supported. |
| Client software | MVS |
Environment and compliance
| Ingress protection | IP40 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: –20 °C to 50 °C (–4 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 5% RH to 90% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | Windows XP/7/10 32/64bits |
|---|
Electrical
| Trigger mode | External trigger, internal trigger |
|---|---|
| External trigger mode | Line trigger, frame trigger, line + frame trigger |
| Power supply | 12~24 VDC |
| Power consumption | 14 W@24 VDC |
Mechanical
| Lens mount | M72*0.75, flange back length 12 mm, applicable to F-mount via lens adapter |
|---|---|
| Dimension | 132 mm × 76 mm × 57.4 mm |
| Weight | F-mount with fan: approx. 600 g (1.3 lb.) |
| Shipping weight (estimated) | 0.94 kg |
