Hikrobot MV-CB050-60UC-C-F 5MP Board Level Camera, USB3.0, FPC, C-mount, Color
  • Hikrobot MV-CB050-60UC-C-F 5MP Board Level Camera, USB3.0, FPC, C-mount, Color
  • MV-CB050-60UC-C-F dimensions (mm)

Board-level cameras

Hikrobot MV-CB050-60UC-C-F 5MP Board Level Camera, USB3.0, FPC, C-mount, Color

Model MV-CB050-60UC-C-FHikrobot

  • Resolution2448 × 2048
  • SensorCMOS, global shutter
  • InterfaceUSB 3.0, compatible with USB 2.0
  • Speed80 fps @ 2448 × 2048 Bayer GR 8
  • Lens mountC-mount
  • Mono / colourColor
$359.00

Ships in 2-3 weeks

0.15 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineerBrowse Board-level cameras

MV-CB050-60UC-C-F: resolution 2448 x 2048; sensor type CMOS, global shutter; sensor size 2/3"; data interface USB 3.0, compatible with USB 2.0; dynamic range 73.9 dB.

Hikrobot MV-CB050-60UC-C-F 5MP Board Level Camera, USB3.0, FPC, C-mount, Color. USB3.0 supports FPC connection to meet limited spatial requirements. Supports auto or manual adjustment of gain, exposure time, white balance, LUT correction, Gamma correction, etc.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHS

Specifications

General

ModelMV-CB050-60UC-C-F
BrandHikrobot
CompatibilityUSB3 Vision, GenICam

Sensor and imaging

Sensor typeCMOS, global shutter
Sensor modelStacked BSI
Pixel size3.45 μm × 3.45 μm
Sensor size2/3"
Resolution2448 × 2048
Max. frame rate80 fps @ 2448 × 2048 Bayer GR 8
Dynamic range73.9 dB
SNR42.4 dB
GainHigh full well capacity: 0 dB to 12.8 dB; High sensitivity: 0 dB to 24 dB
Exposure timeHigh full well capacity: 30 μs to 10 sec; High sensitivity: 5 μs to 10 sec
Exposure modeOff/Once/Continuous exposure mode, supports Trigger Width
Mono/colorColor
Pixel formatMono8; Bayer GR 8/10/10Packed/12/12Packed; YUV422Packed, YUV422_YUYV_Packed; RGB8, BGR8
BinningSupports 1 × 1, 2 × 2, 4 × 4
DecimationSupports 1 × 1, 2 × 2, 4 × 4
Reverse imageSupports horizontal and vertical reverse image output

Interfaces and I/O

Data interfaceUSB 3.0, compatible with USB 2.0
Digital I/OBi-directional non-isolated I/O × 2 (Line 2, Line 5)
Client softwareMVS or third-party software with USB3 Vision Protocol

Environment and compliance

TemperatureWorking temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 80% RH (no condensation)
CertificationCE, RoHS

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux

Electrical

Power supply5 V, USB 3.0 power supply
Power consumptionTyp. 1.5 W @ 5 VDC (USB power supply)

Mechanical

Lens mountC-mount
Dimension29 mm × 29 mm × 31.3 mm (1.1" × 1.1" × 1.2")
WeightApprox. 37 g (0.08 lb.)
Shipping weight (estimated)0.15 kg

Engineering data

Field of view and resolution with the MV-CB050-60UC-C-F

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area8.45 × 7.07 mm2/3" optical format
Lens image circle needed≥ Ø 11 mmC-mount
Pixel pitch3.45 µm2448 x 2048 px
With a 16 mm lens at 500 mm264 × 221 mm0.108 mm per pixel
Dynamic range73.9 dB
SNR42.4 dB
Power consumption1.5 Wtyp. at 5 V DC; USB power supply
ShutterGlobal
Weight37 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm317 × 265 mm0.129 mm per pixel528 × 442 mm0.216 mm per pixel1056 × 884 mm0.431 mm per pixel
12 mm211 × 177 mm0.086 mm per pixel352 × 295 mm0.144 mm per pixel704 × 589 mm0.288 mm per pixel
16 mm158 × 133 mm0.065 mm per pixel264 × 221 mm0.108 mm per pixel528 × 442 mm0.216 mm per pixel
25 mm101 × 84.8 mm0.041 mm per pixel169 × 141 mm0.069 mm per pixel338 × 283 mm0.138 mm per pixel
35 mm72.4 × 60.6 mm0.03 mm per pixel121 × 101 mm0.049 mm per pixel241 × 202 mm0.099 mm per pixel
50 mm50.7 × 42.4 mm0.021 mm per pixel84.5 × 70.7 mm0.035 mm per pixel169 × 141 mm0.069 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount, image circle, resolution and spectral band, and the camera's printed connector for cables.

Build the full system with this part

Lenses for this C-mount camera

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Cables and frame grabbers

5 m USB3.0 camera cable

LS-CBL-0218

  • Type USB3.0 Cable
  • Construction Standard (straight, not high-flex)

$54.00

Ships in 3-4 weeks
