Hikrobot MV-CB020-60UC-C 2MP Board Level Camera, USB3, Color, C-mount
Model MV-CB020-60UC-CHikrobot
- Resolution1624 × 1240
- SensorCMOS, global shutter
- InterfaceUSB 3.0, compatible with USB 2.0
- Speed179.9 fps @ 1624 × 1240 Bayer GB 8
- Lens mountC-mount
- Mono / colourColor
$229.00
Ships in 2-3 weeks
0.14 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CB020-60UC-C 2MP Board Level Camera, USB3, Color, C-mount. Supports auto and manual adjustment for gain, exposure control, white balance, LUT, etc. Adopts image interpolation algorithm for color camera to have better color correction.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CB020-60UC-C |
|---|---|
| Brand | Hikrobot |
| Compatibility | USB3 Vision, GenICam |
Sensor and imaging
| Sensor type | CMOS, global shutter |
|---|---|
| Sensor model | Stacked BSI |
| Pixel format | Mono 8; Bayer GB 8/10/10Packed/12/12Packed; YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8 |
| Pixel size | 3.45 μm × 3.45 μm |
| Sensor size | 1/2.53" |
| Resolution | 1624 × 1240 |
| Max. frame rate | 179.9 fps @ 1624 × 1240 Bayer GB 8 |
| Dynamic range | 68.6 dB |
| SNR | 44.1 dB |
| Gain | 0 dB to 24 dB |
| Exposure time | 23 μs to 10 sec |
| Exposure mode | Off/ Once/ Continuous exposure mode |
| Mono/color | Color |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
Interfaces and I/O
| Data interface | USB 3.0, compatible with USB 2.0 |
|---|---|
| Digital I/O | Bi-directional non-isolated I/O × 2 (Line 2, Line 5) |
| Client software | MVS or third-party software with USB3 Vision Protocol |
Environment and compliance
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
|---|---|
| Humidity | 20% RH to 80% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | 32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux |
|---|
Electrical
| Power supply | USB 3.0 power supply |
|---|---|
| Power consumption | Typ. 1.6 W @ 5 VDC |
Mechanical
| Lens mount | C-mount |
|---|---|
| Dimension (without lens) | 35 mm × 35 mm × 8.6 mm (1.4" × 1.4" × 0.3") |
| Weight | Approx. 30 g (0.07 lb.) |
| Shipping weight (estimated) | 0.14 kg |
