Lenses

2/3-inch machine vision lenses

Fixed-focal-length C-mount lenses from 1/1.8" to 4/3" formats, macro lenses, telecentric lenses for measurement, and 4K to 16K line-scan lenses. Lenses rated for 2/3-inch sensors cover an image circle of at least 11 mm, so they also suit smaller sensors; on a larger sensor the corners go dark (vignetting).

All machine vision lenses · 4/3-inch machine vision lenses · 1.1-inch machine vision lenses · 1-inch machine vision lenses · 1/1.7-inch machine vision lenses · 1/1.8-inch machine vision lenses · 1/2-inch machine vision lenses · 1/2.5-inch machine vision lenses · APS-C machine vision lenses · Full frame machine vision lenses

516 models Configure a system All lenses

Products

									Compare
LS-FFL-066625 mm, 2/3", 5 MP, C-mount machine vision lens	25 mm	C-mount	2/3"	F1.4 manual iris	5.0 MP	-	$199.00	Ships in 2-3 weeks	Compare LS-FFL-0666
LS-FFL-066416 mm, 2/3", 8 MP, C-mount machine vision lens, M28.5 x 0.5 mm filter thread	16 mm	C-mount	2/3"	F2.8 Manual iris	8.0 Megapixel	0.073X @ 200 mm WD	$209.00	Ships in 2-3 weeks	Compare LS-FFL-0664
LS-FFL-066316 mm, 2/3", 10 MP, C-mount machine vision lens, F2.0 Manual iris	16 mm	C-mount	2/3"	F2.0 Manual iris	10 Megapixel	-	$319.00	Ships in 2-3 weeks	Compare LS-FFL-0663
LS-FFL-066216 mm, 2/3", 10 MP, C-mount machine vision lens, F1.8 manual iris	16 mm	C-mount	2/3"	F1.8 manual iris	10 MP	-	$319.00	Ships in 2-3 weeks	Compare LS-FFL-0662
LS-FFL-066116 mm, 2/3", 8 MP, C-mount machine vision lens	16 mm	C-mount	2/3"	F1.4 Manual Iris	8.0 Megapixel	-	$209.00	Ships in 2-3 weeks	Compare LS-FFL-0661
LS-FFL-066016 mm, 2/3", 5 MP, C-mount machine vision lens	16 mm	C-mount	2/3"	F1.4 Manual Iris	5.0 Megapixel	-	$209.00	Ships in 2-3 weeks	Compare LS-FFL-0660
LS-FFL-065916 mm, 2/3", 5 MP, C-mount machine vision lens	16 mm	C-mount	2/3"	F1.4 manual iris	5.0 MP	-	$209.00	Ships in 2-3 weeks	Compare LS-FFL-0659
LS-FFL-064012 mm, 2/3", 8 MP, C-mount machine vision lens, F1.4 Manual iris	12 mm	C-mount	2/3"	F1.4 Manual iris	8.0 Megapixel	-	$179.00	Ships in 2-3 weeks	Compare LS-FFL-0640
LS-FFL-065712 mm, 2/3", 8 MP, C-mount machine vision lens, 2/3" (dia. 11 mm), F2.8 Manual iris	12 mm	C-mount	2/3"	F2.8 Manual iris	8.0 Megapixel	0.10214X @ 100 mm WD	$179.00	Ships in 2-3 weeks	Compare LS-FFL-0657
LS-FFL-065612 mm, 2/3", 10 MP, C-mount machine vision lens, F2.0 Manual iris, 11.4 mm image circle	12 mm	C-mount	2/3"	F2.0 Manual iris	10 Megapixel	-	$309.00	Ships in 2-3 weeks	Compare LS-FFL-0656
LS-FFL-065512 mm, 2/3", 10 MP, C-mount machine vision lens, F2.0 manual iris, 11 mm image circle	12 mm	C-mount	2/3"	F2.0 manual iris	10 MP	-	$309.00	Ships in 2-3 weeks	Compare LS-FFL-0655
LS-FFL-065412 mm, 2/3", 8 MP, C-mount machine vision lens, F1.4 Manual Iris, 40.8 x 31 deg angle of view	12 mm	C-mount	2/3"	F1.4 Manual Iris	8.0 Megapixel	-	$179.00	Ships in 2-3 weeks	Compare LS-FFL-0654
LS-FFL-065312 mm, 2/3", 5 MP, C-mount machine vision lens, F1.4 Manual Iris, M30.5 x P0.5 filter thread	12 mm	C-mount	2/3"	F1.4 Manual Iris	5.0 Megapixel	-	$179.00	Ships in 2-3 weeks	Compare LS-FFL-0653
LS-FFL-065212 mm, 2/3", 5 MP, C-mount machine vision lens, F1.4 manual iris	12 mm	C-mount	2/3"	F1.4 manual iris	5.0 MP	-	$179.00	Ships in 2-3 weeks	Compare LS-FFL-0652
LS-FFL-06518 mm, 2/3", 10 MP, C-mount machine vision lens, F2.8 Manual iris	8 mm	C-mount	2/3"	F2.8 Manual iris	10 Megapixel	-	$309.00	Ships in 2-3 weeks	Compare LS-FFL-0651
LS-FFL-06508 mm, 2/3", 5 MP, C-mount machine vision lens	8.0 mm	C-mount	2/3"	F2.5 Manual iris	5.0 Megapixel	-	$169.00	Ships in 2-3 weeks	Compare LS-FFL-0650
LS-FFL-06498 mm, 2/3", 10 MP, C-mount machine vision lens, F2.4 manual iris	8 mm	C-mount	2/3"	F2.4 manual iris	10 MP	-	$309.00	Ships in 2-3 weeks	Compare LS-FFL-0649
LS-FFL-06478 mm, 2/3", 5 MP, C-mount machine vision lens	8 mm	C-mount	2/3"	F1.4 Manual Iris	5.0 MP	-	$169.00	Ships in 2-3 weeks	Compare LS-FFL-0647
LS-FFL-06468 mm, 2/3", 5 MP, C-mount machine vision lens	8 mm	C-mount	2/3"	F1.4-16 Manual iris	5.0 Megapixel	-	$169.00	Ships in 2-3 weeks	Compare LS-FFL-0646
LS-FFL-06456 mm, 2/3", 5 MP, C-mount machine vision lens, F1.9-16 Manual iris	6 mm	C-mount	2/3"	F1.9-16 Manual iris	5.0 Megapixel	-	$239.00	Ships in 2-3 weeks	Compare LS-FFL-0645
LS-FFL-06446 mm, 2/3", 5 MP, C-mount machine vision lens, F1.4-C	6 mm	C-mount	2/3"	F1.4 to closed	5.0 Megapixel	-	$239.00	Ships in 2-3 weeks	Compare LS-FFL-0644
LS-FFL-06435 mm, 2/3", 6 MP, C-mount machine vision lens	5 mm	C-mount	2/3"	F2.8-16	6 MP	-	$229.00	Ships in 2-3 weeks	Compare LS-FFL-0643
LS-FFL-06424 mm, 2/3", 6 MP, C-mount machine vision lens	4 mm	C-mount	2/3"	F2.8 manual iris	6.0 MP	0.0351x @ 100 mm WD	$229.00	Ships in 2-3 weeks	Compare LS-FFL-0642
LS-FFL-151725 mm, 2/3", 10 MP, C-mount motorized-focus lens, 25.0 +/-0.3 mm	25.0 +/-0.3 mm	C-mount	2/3"	F2.0	10 MP	-	$1,099.00	Ships in 2-3 weeks	Compare LS-FFL-1517
