2/3" machine vision lenses
  • 2/3" machine vision lenses
  • LS-SMV0826CL-10M dimensions (mm)

Machine vision lenses

8 mm, 2/3", 10 MP, C-mount Machine Vision Lens, 10 Megapixel, F2.8 Manual iris (LS-FFL-0651)

Model LS-FFL-0651

  • Focal length8 mm
  • MountC-mount
  • Sensor2/3"
  • ApertureF2.8 Manual iris
  • Resolution10 Megapixel
$309.00

In stock - ships the same business day (3 available, order by 2 PM ET)

0.26 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

8 mm, 2/3", 10 MP, C-mount Machine Vision Lens, 10 Megapixel, F2.8 Manual iris (LS-FFL-0651)LS-FFL-0651

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

8 mm, 2/3", 10 MP, C-mount Machine Vision Lens. Compact (<29 mm diameter) 8 mm F2.8 manual-iris machine vision lens for 2/3" sensors, rated 10 megapixel (4K, 1080P), covering 2/3", 1/1.8" and 1/2" cameras. For automation, inspection, 3D, SMT and AOI. At a glance: focal length 8 mm; format 2/3"; resolution 10 Megapixel; aperture F2.8 Manual iris; mount C.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-0651
Format2/3"
Angle of view (2/3")67.2 x 53.5 x 46 deg
Angle of view (1/1.8")56.6 x 45 x 34.1 deg
Angle of view (1/2")51.4 x 42 x 32.1 deg
B.F.L.10.5 mm @ MOD in air; 9.7 mm @ infinity in air

Optics

Focal length8 mm
Max image circledia. 11.4 mm
ApertureF2.8 Manual iris
M.O.D.0.11 m
Distortion-1.98%@0.11 m ; -0.89%@0.4 m

Sensor and imaging

Resolution10 Megapixel

Mechanical

Sizedia. 29 x 43.23 mm
Filter sizeM27 x P0.5
MountC
Weight115 g
Shipping weight (estimated)0.26 kg

Other models in the 2/3" machine vision lenses (LS-FFL-S90) series

See all 50 models
ModelSize / key dataPriceAvailabilityLink
LS-FFL-0678 35 mm, 2/3", 8 MP, C-mount $219.00 5 in stock View
LS-FFL-0679 35 mm, 2/3", 6 MP, C-mount $219.00 2 in stock View
LS-FFL-0641 4 mm, 2/3" $229.00 Quote Ships in 2-3 weeks View
LS-FFL-0642 4 mm, 2/3", 6 MP, C-mount $229.00 4 in stock View
LS-FFL-0643 5 mm, 2/3", 6 MP, C-mount $229.00 4 in stock View
LS-FFL-0644 6 mm, 2/3", 5 MP, C-mount $239.00 2 in stock View
LS-FFL-0645 6 mm, 2/3", 5 MP, C-mount $239.00 2 in stock View
LS-FFL-0680 50 mm, 2/3", 5 MP, C-mount $249.00 2 in stock View
LS-FFL-0681 50 mm, 2/3", 5 MP, C-mount $249.00 5 in stock View
LS-FFL-0684 50 mm, 2/3", 8 MP, C-mount $249.00 4 in stock View
LS-FFL-0685 50 mm, 2/3", 6 MP, C-mount $249.00 4 in stock View
LS-FFL-0649 8 mm, 2/3", 10 MP, C-mount $309.00 4 in stock View
LS-FFL-0655 12 mm, 2/3", 10 MP, C-mount $309.00 2 in stock View
LS-FFL-0656 12 mm, 2/3", 10 MP, C-mount $309.00 3 in stock View
LS-FFL-0686 75 mm, 2/3", 5 MP, C-mount $309.00 3 in stock View
LS-FFL-0687 75 mm, 2/3", 2 MP, C-mount $309.00 2 in stock View
LS-FFL-0662 16 mm, 2/3", 10 MP, C-mount $319.00 4 in stock View
LS-FFL-0663 16 mm, 2/3", 10 MP, C-mount $319.00 5 in stock View
LS-FFL-0669 25 mm, 2/3", 10 MP, C-mount $339.00 5 in stock View
LS-FFL-0670 25 mm, 2/3", 10 MP, C-mount $339.00 3 in stock View
LS-FFL-0688 100 mm, 2/3", 2 MP, C-mount $359.00 3 in stock View
LS-FFL-0676 35 mm, 2/3", 10 MP, C-mount $359.00 3 in stock View
LS-FFL-0677 35 mm, 2/3", 10 MP, C-mount $359.00 5 in stock View
LS-FFL-0682 50 mm, 2/3", 10 MP, C-mount $389.00 5 in stock View
