Dome lights · 11 models · from $89.00
3.0 dome light (3DM series)
The 3.0 dome light (3DM series) is a range of 11 dome lights from LumaSpec Vision, from $89.00. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Colour | Red, Green, Blue, White |
|---|---|
| Size | Under 50 mm, 50-100 mm, 100-200 mm, 200-400 mm |
| Voltage | 24 V |
| Connector | SM3 |
Features
- Diffused light from the dome for reflective and uneven surfaces
- SMD LEDs
- Three-colour RGB light source, outer/inner diameter and height, wavelength/colour temperature, mounting and input wire length customization
- Diameter of light inlet: 20mm. Diameter of light outlet: 40mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:50000 hours for red light and 30000 hours for white light.
- Suitable for detecting reflective, uneven surface, curved surface defects, etc.
Typical uses
- Detecting reflective, uneven surfaces
- Surface, concave and convex surface, arc surface detection
- Packaging industry (beverage container top)
All 11 models in the 3.0 dome light (3DM series)
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-3DM4020 | 4.2 W | $89.00 | 13 in stock | View | ||
| LS-3DM5620 | 5.2 W | $189.00 | 14 in stock | View | ||
| LS-3DM7420 | 6.3 W | $239.00 | 15 in stock | View | ||
| LS-3DM9624 | 8.2 W | $299.00 | 12 in stock | View | ||
| LS-3DM13034 | 11.7 W | $419.00 | 15 in stock | View | ||
| LS-3DM14330 | 12.2 W | $519.00 | 18 in stock | View | ||
| LS-3DM17750 | 19.5 W | $669.00 | 18 in stock | View | ||
| LS-3DM20548 | 26.3 W | $789.00 | 12 in stock | View | ||
| LS-3DM24548 | 26.8 W | $989.00 | 12 in stock | View | ||
| LS-3DM31760 | 40 W | $1,109.00 | 13 in stock | View | ||
| LS-3DM29050 | 38 W | $1,239.00 | 13 in stock | View |
