Hikrobot MV-CH089-60GC V5 8.9MP Area Scan Camera, GigE, Color
  • Hikrobot MV-CH089-60GC V5 8.9MP Area Scan Camera, GigE, Color
  • MV-CH089-60GC V5 dimensions (mm)

Area scan cameras

Hikrobot MV-CH089-60GC V5 8.9MP Area Scan Camera, GigE, Color

Model MV-CH089-60GC V5Hikrobot

  • Resolution4096 × 2160
  • SensorCMOS, global shutter
  • Speed13.9 fps @ 4096 × 2160 Bayer GB 8
  • Lens mountC-mount
  • Mono / colourColor
  • Pixel size3.45 μm × 3.45 μm
$1,659.00

Ships in 2-3 weeks

0.24 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable cameras:

Ask an engineerBrowse Area scan cameras

MV-CH089-60GC V5: resolution 4096 x 2160, sensor size 1", dynamic range 67.2 dB, SNR 44.1 dB, mono/color Color.

Hikrobot MV-CH089-60GC V5 8.9MP Area Scan Camera, GigE, V5, Color. Compact design with mounting holes on panels for flexible mounting from 4 sides. Supports auto or manual adjustment of gain and exposure time, and LUT and Gamma correction function.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHSKC

Specifications

General

ModelMV-CH089-60GC V5
BrandHikrobot
CompatibilityGigE Vision 2.0, GenICam

Sensor and imaging

Sensor typeCMOS, global shutter
Sensor modelStacked BSI
Pixel size3.45 μm × 3.45 μm
Sensor size1"
Resolution4096 × 2160
Max. frame rate13.9 fps @ 4096 × 2160 Bayer GB 8
Dynamic range67.2 dB
SNR44.1 dB
Gain0 dB to 12 dB
Exposure timeUltraShort exposure mode: 10 μs to 19 μs; Standard exposure mode: 20 μs to 10 sec
Exposure modeOff/Once/Continuous exposure mode, supports TriggerWidth
Pixel formatMono 8, Bayer GB 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed, RGB 8, BGR 8
BinningSupports 1 × 1, 2 × 2, 4 × 4
DecimationSupports 1 × 1, 2 × 2, 4 × 4
Reverse imageSupports horizontal and vertical reverse image output
Mono/colorColor

Interfaces and I/O

Data interfaceGigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2)
Client softwareMVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protectionIP 40 (under proper lens installation and wiring)
TemperatureWorking temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 95% RH (no condensation)
CertificationCE, RoHS, KC

Computing

Operating system32/64-bit Windows 7/10/11, 32/64-bit Linux

Electrical

Power supply9 VDC to 24 VDC, supports PoE
Power consumptionTyp. 1.8 W @ 12 VDC

Mechanical

Lens mountC-mount
Dimension (without lens)29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
WeightApprox. 100 g (0.2 lb.)
Shipping weight (estimated)0.24 kg

Engineering data

Field of view and resolution with the MV-CH089-60GC V5

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area14.13 × 7.45 mm1" optical format
Lens image circle needed≥ Ø 16 mmC-mount
Pixel pitch3.45 µm4096 x 2160 px
Image data at max frame rate123 MB/sCalculated: 13.9 fps × 4096 × 2160 px at 8 bit · GigE carries 125 MB/s nominal
With a 16 mm lens at 500 mm442 × 233 mm0.108 mm per pixel
Dynamic range67.2 dB
SNR44.1 dB
Power consumption1.8 Wtyp. at 12 V DC
ShutterGlobal
Exposure range20 µs to 10 sstandard mode
Weight100 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm530 × 279 mm0.129 mm per pixel883 × 466 mm0.216 mm per pixel1766 × 931 mm0.431 mm per pixel
12 mm353 × 186 mm0.086 mm per pixel589 × 310 mm0.144 mm per pixel1178 × 621 mm0.287 mm per pixel
16 mm265 × 140 mm0.065 mm per pixel442 × 233 mm0.108 mm per pixel883 × 466 mm0.216 mm per pixel
25 mm170 × 89.4 mm0.041 mm per pixel283 × 149 mm0.069 mm per pixel565 × 298 mm0.138 mm per pixel
35 mm121 × 63.9 mm0.03 mm per pixel202 × 106 mm0.049 mm per pixel404 × 213 mm0.099 mm per pixel
50 mm84.8 × 44.7 mm0.021 mm per pixel141 × 74.5 mm0.034 mm per pixel283 × 149 mm0.069 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Lenses for this C-mount camera

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Covers up to 16 mm diagonal; this camera's sensor is 16 mm

Cables and frame grabbers
