CCTV lenses
6.5-20 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens (LS-SVD6520IR-3M)
Model LS-SVD6520IR-3M
- Focal length6.5-20 mm
- MountC-mount
- Sensor2/3"
- ApertureF1.4 DC Iris
- Resolution3 Megapixel
$39.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.28 kg shipping weight
Volume pricing, Net 30 or a formal quote?
6.5-20 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens. 6.5-20 mm, 3 megapixel IR-corrected varifocal lens for 2/3" cameras with F1.4 DC iris. At a glance: focal length 6.5-20 mm; format 2/3"; resolution 3 Megapixel; aperture F1.4 DC Iris; mount C.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SVD6520IR-3M |
|---|---|
| IR corrected | IR |
| Format | 2/3" |
| Angle of view (2/3", DxHxV) | W 96 x 74 x 54 deg / T 32 x 27 x 20 deg |
| Notes | -20~+100° |
| IR correction | IR |
| Angle of view (2/3") | W: 96 x 74 x 54 | T: 32 x 27 x 20 deg |
| B.F.L. | 12-21.39 mm |
| T.T.L. | 75.9 mm |
Optics
| Focal length | 6.5-20 mm |
|---|---|
| Aperture | F1.4 DC Iris |
| M.O.D. | 0.3 m |
| Back focal length | 12-21.39 mm |
Sensor and imaging
| Resolution | 3 Megapixel |
|---|
Mechanical
| Size | dia. 43.4 x 57.02 |
|---|---|
| Total track length | 75.9 mm |
| Mount | C |
| Weight | 130 g |
| Shipping weight (estimated) | 0.28 kg |
