Hikrobot MV-DB700S-C V3.0 RGB-D Smart 3D Camera (Low Clearance EDP)

Model MV-DB700S-C V3.0Hikrobot

InterfaceGigabit Ethernet (1000 Mbit/s)
Speed30 fps @ EDP mode
TypeLogistics / volume
Near field of view590 mm × 470 mm

$3,229.00

List price

Ships in 2-3 weeks

1.08 kg shipping weight

Not available in the United States. Available for delivery to other countries.

MV-DB700S-C V3.0: measurement range (MR) 700 mm, clearance distance (CD) 300 mm, near field of view 590 mm x 470 mm, scan frame rate 30 fps @ EDP mode.

Hikrobot MV-DB700S-C V3.0 RGB-D Smart 3D Camera. Adopts built-in deep learning algorithm and 3D image process algorithm. Large field of view, suitable for scenes with limited working distances.

Tracked worldwide shippingTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)KCCE

Specifications

General

Model	MV-DB700S-C V3.0
Brand	Hikrobot
Clearance distance (CD)	300 mm
Measurement range (MR)	700 mm
Object detection range	500 mm installation height: 50 mm × 50 mm × 10 mm to 450 mm × 450 mm × 200 mm
Depth image detection accuracy	Z: 2.5 mm @ 0.5 m, 5 mm @ 1 m
Data type	Original image (mono and color images), depth image, EDP detection result
Laser safety class	Class 1

Optics

Near field of view	590 mm × 470 mm
Far field of view	2200 mm × 1500 mm

Sensor and imaging

Resolution	Depth: 1408 × 1024 @ 30 fps; RGB: 1536 × 1280 @ 30 fps
Scan frame rate	30 fps @ EDP mode

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s)
Digital I/O	12-pin M12 interface provides power and I/O, including opto-isolated input × 3 (Line 0/3/6), opto-isolated output × 3 (Line 1/4/7)
Client software	HiViewer

Environment and compliance

Ingress protection	IP65
Temperature	Working temperature: 0 °C to 45 °C (32 °F to 113 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 85% RH (no condensation)
Certification	KC, CE

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Windows 11

Electrical

Power supply	12 VDC to 24 VDC
Power consumption	Typ. 8.2 W @ 24 VDC

Mechanical

Dimension	184 mm × 55 mm × 53 mm (7.2" × 2.2" × 2.1")
Weight	Approx. 700 g (1.5 lb.)
Shipping weight (estimated)	1.08 kg

Downloads

Features

12 V DC supply
KC and CE compliant
Adopts built-in deep learning algorithm and 3D image process algorithm.
Large field of view, suitable for scenes with limited working distances.
High-efficient laser module and accurate exposure synchronization provide stable performance and wider dynamic range.
Adopts narrow band filters to have stronger anti-interference ability.
Support one-click system calibration of single camera.
Ingress Protection (IP) 65.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Other models in the Express Logistics series

See all 14 models

Model	Interface	Speed	Type	Price	Availability	Link
MV-DB700S-C V3.0This model	Gigabit Ethernet (1000 Mbit/s)	30 fps @ EDP mode	Logistics / volume	$3,229.00 Quote	Ships in 2-3 weeks	Compare
MV-DB300S-V	Gigabit Ethernet(1000Mbit/s)		Logistics / volume	$1,009.00 Quote	Ships in 2-3 weeks	CompareView
MV-DB500S-C V3.0	Gigabit Ethernet (1000 Mbit/s)	20 fps @ EDP mode	Logistics / volume	$3,199.00 Quote	Ships in 2-3 weeks	CompareView
