Hikrobot MV-CH050-90TC-C-NF 5MP Area Scan Camera, GMAX3405, 10GigE, Color, C-mount, with fan
  • Hikrobot MV-CH050-90TC-C-NF 5MP Area Scan Camera, GMAX3405, 10GigE, Color, C-mount, with fan
  • MV-CH050-90TC-C-NF dimensions (mm)

Area scan cameras

Hikrobot MV-CH050-90TC-C-NF 5MP Area Scan Camera, GMAX3405, 10GigE, Color, C-mount, with fan

Model MV-CH050-90TC-C-NFHikrobot

  • Resolution2448 × 2048
  • SensorCMOS, global shutter
  • Speed163.4 fps @ 2448 × 2048 Bayer GB 8
  • Lens mountC-mount
  • Mono / colourColor
  • Pixel size3.4 μm × 3.4 μm
$3,599.00
List price

Ships in 2-3 weeks

0.4 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineerBrowse Area scan cameras

MV-CH050-90TC-C-NF: resolution 2448 x 2048; sensor type CMOS, global shutter; sensor size 2/3"; dynamic range 66.1 dB.

Hikrobot MV-CH050-90TC-C-NF 5MP Area Scan Camera, GMAX3405, 10GigE, Color, C-mount, with fan. Resolution of 2448 × 2048, and pixel size of 3.4 μm × 3.4 μm. Compatible with C-mount lens.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHSKC

Specifications

General

ModelMV-CH050-90TC-C-NF
BrandHikrobot
CompatibilityGigE Vision V2.0, GenICam

Sensor and imaging

Sensor typeCMOS, global shutter
Sensor modelGpixel GMAX3405
Pixel size3.4 μm × 3.4 μm
Sensor size2/3"
Resolution2448 × 2048
Max. frame rate163.4 fps @ 2448 × 2048 Bayer GB 8
Dynamic range66.1 dB
SNR39.2 dB
Gain0 dB to 6.1 dB
Exposure time2 μs to 10 sec
Exposure modeOff/Once/Continuous exposure mode, supports Trigger Width
Mono/colorColor
Pixel formatBayer GB 8/10/10Packed/12/12Packed
BinningSupports 1 × 1, 2 × 2, 4 × 4
DecimationSupports 1 × 1, 2 × 2, 4 × 4
Reverse imageSupports horizontal and vertical reverse image output

Interfaces and I/O

Data interface10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
Digital I/O6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), and bi-directional non-isolated I/O × 1 (Line 2).
Client softwareMVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protectionIP40 (under proper lens installation and wiring)
TemperatureWorking temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 95% RH (no condensation)
CertificationCE, RoHS, KC

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux

Electrical

Power supply9 VDC to 24 VDC
Power consumptionTyp. 8.4 W @ 12 VDC

Mechanical

Lens mountC-mount
Dimension50 mm × 45 mm × 68.6 mm (2.0" × 1.8" × 2.7")
WeightApprox. 212 g (0.5 lb.)
Shipping weight (estimated)0.40 kg

Engineering data

Field of view and resolution with the MV-CH050-90TC-C-NF

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area8.32 × 6.96 mm2/3" optical format
Lens image circle needed≥ Ø 10.8 mmC-mount
Pixel pitch3.4 µm2448 x 2048 px
Image data at max frame rate819 MB/sCalculated: 163.4 fps × 2448 × 2048 px at 8 bit · 10GigE carries 1250 MB/s nominal
With a 16 mm lens at 500 mm260 × 218 mm0.106 mm per pixel
Dynamic range66.1 dB
SNR39.2 dB
Power consumption8.4 Wtyp. at 12 V DC
ShutterGlobal
Exposure range2 µs to 10 s
Weight212 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm312 × 261 mm0.127 mm per pixel520 × 435 mm0.212 mm per pixel1040 × 870 mm0.425 mm per pixel
12 mm208 × 174 mm0.085 mm per pixel347 × 290 mm0.142 mm per pixel693 × 580 mm0.283 mm per pixel
16 mm156 × 130 mm0.064 mm per pixel260 × 218 mm0.106 mm per pixel520 × 435 mm0.212 mm per pixel
25 mm99.8 × 83.5 mm0.041 mm per pixel166 × 139 mm0.068 mm per pixel333 × 278 mm0.136 mm per pixel
35 mm71.3 × 59.7 mm0.029 mm per pixel119 × 99.4 mm0.049 mm per pixel238 × 199 mm0.097 mm per pixel
50 mm49.9 × 41.8 mm0.02 mm per pixel83.2 × 69.6 mm0.034 mm per pixel166 × 139 mm0.068 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.
