Hikrobot MV-CH250-90TC-M58S-NF V2 25MP Area Scan Camera, 10GigE, GMAX0505, Color, M58-mount, with fan, V2
Model MV-CH250-90TC-M58S-NF V2Hikrobot
- Resolution5120 × 5120
- SensorCMOS, global shutter
- Speed41.6 fps @ 5120 × 5120 Bayer BG 8
- Lens mountC-mount
- Mono / colourColor
- Pixel size2.5 μm × 2.5 μm
$2,649.00
Quoted price: add to quote for lead time and volume pricing.
Ships in 2-3 weeks
0.93 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CH250-90TC-M58S-NF V2 25MP Area Scan Camera, 10GigE, GMAX0505, Color, M58-mount, with fan, V2. Resolution of 5120 × 5120, pixel size of 2.5 μm × 2.5 μm. Compatible with C-mount lenses to reduce costs.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CH250-90TC-M58S-NF V2 |
|---|---|
| Brand | Hikrobot |
| Compatibility | GigE Vision V2.0, GenlCam |
Sensor and imaging
| Sensor type | CMOS, global shutter |
|---|---|
| Sensor model | Gpixel GMAX0505 |
| Pixel size | 2.5 μm × 2.5 μm |
| Sensor size | 1.1" |
| Resolution | 5120 × 5120 |
| Max. frame rate | 41.6 fps @ 5120 × 5120 Bayer BG 8 |
| Dynamic range | 63 dB |
| SNR | 36 dB |
| Gain | 1.0x to 5.0x |
| Exposure time | UltraShort exposure mode: 3 μs to 8 μs; Standard exposure mode: 9 μs to 10 sec |
| Exposure mode | Off/Once/Continuous exposure mode |
| Mono/color | Color |
| Pixel format | Mono 8/10/12; Bayer BG 8/10/10Packed/12/12Packed; YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8 |
| Binning | Supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
Interfaces and I/O
| Data interface | 10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s) |
|---|---|
| Digital I/O | 12-pin P10 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2), and RS-232 × 1 |
| Client software | MVS or third-party software meeting with GigE Vision Protocol |
Environment and compliance
| Ingress protection | IP40 ( under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | 32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux |
|---|
Electrical
| Power supply | 9 VDC to 24 VDC |
|---|---|
| Power consumption | Typ. 10.5 W @ 12 VDC |
Mechanical
| Lens mount | C-mount; M58*0.75, flange back length 11.48 mm |
|---|---|
| Dimension | 74 mm × 74 mm × 78.8 mm (2.9" × 2.9" × 3.1") |
| Weight | C-mount: Approx. 590 g (1.3 lb.); M58-mount: Approx. 550 g (1.2 lb.) |
| Shipping weight (estimated) | 0.93 kg |
