FA lens, 35 mm, 2/3", C-mount, FOV 13.1° (LS-FFL-1586)
  • FA lens, 35 mm, 2/3", C-mount, FOV 13.1° (LS-FFL-1586)
  • LS-FFL-1586 dimensions (mm)

Representative photo of this series

Machine vision lenses

FA lens, 35 mm, 2/3", C-mount, FOV 13.1° (LS-FFL-1586)

Model LS-FFL-1586

  • Focal length35 mm
  • MountC-mount
  • Sensor2/3"
  • Aperture1:2.8~16
  • Resolution10 MP
  • Field of view13.1°
$359.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

FA lens, 35 mm, 2/3", C-mount, FOV 13.1° (LS-FFL-1586)LS-FFL-1586

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-FFL-1586: focal length 35 mm, sensor format 2/3", aperture F1:2.8-16, object dimension at M.O.D H (2/3"(8.8*6.6mm)) 50.7 mm.

FA lens series: compact design, adjustable aperture, ultra-high resolution and minimized distortion; supports 1/1.8", 1/1.7", 2/3", 1" sensors, max sensor 1.1".

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-1586
Angle H (2/3"(8.8*6.6mm))13.1°
Angle H (1/2"(6.4*4.8mm))9.5°
Angle H (1/3"(4.8*3.6mm))7.2°
Angle V (2/3"(8.8*6.6mm))9.9°
Angle V (1/2"(6.4*4.8mm))7.2°
Angle V (1/3"(4.8*3.6mm))5.5°
Angle D (2/3"(8.8*6.6mm))16.3°
Angle D (1/2"(6.4*4.8mm))11.9°
Angle D (1/3"(4.8*3.6mm))8.8°
Flange back17.526mm in air
Front/Rear Effective Diadia. 16.8mm/dia. 11mm

Optics

Object Dimension at M.O.D H (2/3"(8.8*6.6mm))50.7 mm
Object Dimension at M.O.D H (1/2"(6.4*4.8mm))36.8 mm
Object Dimension at M.O.D H (1/3"(4.8*3.6mm))27.2 mm
Object Dimension at M.O.D V (2/3"(8.8*6.6mm))38 mm
Object Dimension at M.O.D V (1/2"(6.4*4.8mm))27.6 mm
Object Dimension at M.O.D V (1/3"(4.8*3.6mm))20.4 mm
Object Dimension at M.O.D D (2/3"(8.8*6.6mm))63.2 mm
Object Dimension at M.O.D D (1/2"(6.4*4.8mm))46 mm
Object Dimension at M.O.D D (1/3"(4.8*3.6mm))34 mm
Focus distance(min)0.1M
Back focus16.55mm in air
Filter screw sizeM27x0.5
Aperture1:2.8~16
Focal length35 mm
Field of view H13.1°
Field of view V9.9°
Field of view D16.3°
Distortion<0.1%

Sensor and imaging

Sensor format2/3"
Resolution10 MP

Environment and compliance

Temperature range-10 to 50 °C
Storage temperature range-20 to 60 °C

Mechanical

MountC-Mount
Max Diameter(RATIO)F=1:2.8~16
Picture size2/3"(8.8*6.6mm) / 1/2"(6.4*4.8mm) / 1/3"(4.8*3.6mm)
Shipping weight0.38 kg

Engineering data

Field of view with the LS-FFL-1586

Worked out from this lens's own focal length, image circle and closest focus: what it sees at your working distance, on the sensor you use.

Focal length35 mm
Image circleØ 11 mmCovers sensors up to 2/3"
Angle of view13.8° × 11.5°Calculated for a 2/3" sensor; 17.9° diagonal
Closest focus50.7 mm
Distortion< 0.1 %
Back focal length16.55 mmin air
Flange distance17.526 mmin air
Filter threadM27 × 0.5
Field of view (width × height) of the 35 mm lens by sensor format and working distance
Sensor formatAt 140 mmAt 300 mmAt 1000 mmAt 2000 mm
1/2.9"4.98 × 3.74 mm19.9 × 15 mm42.7 × 32.1 mm142 × 107 mm285 × 214 mm
1/2"6.4 × 4.8 mm25.6 × 19.2 mm54.9 × 41.1 mm183 × 137 mm366 × 274 mm
1/1.8"7.07 × 5.3 mm28.3 × 21.2 mm60.6 × 45.4 mm202 × 151 mm404 × 303 mm
2/3"8.45 × 7.07 mm33.8 × 28.3 mm72.4 × 60.6 mm241 × 202 mm483 × 404 mm

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length, with the distance measured to the front of the lens; closest to reality when the distance is many times the focal length. Sensor sizes are typical for each optical format.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Cameras this lens fits

7.1 mm sensor diagonal; this lens covers up to 11 mm

9.5 mm sensor diagonal; this lens covers up to 11 mm

3.2 mm sensor diagonal; this lens covers up to 11 mm

6.6 mm sensor diagonal; this lens covers up to 11 mm

8.9 mm sensor diagonal; this lens covers up to 11 mm

8.8 mm sensor diagonal; this lens covers up to 11 mm

Adapters

For CS-mount cameras

Other models in the FA lens, C-mount (LS-FFL-S151) series

See all 41 models
ModelFocal lengthSensorAperturePriceAvailabilityLink
LS-FFL-1586This model35 mm2/3"1:2.8~16$359.00 Ships in 2-3 weeks
LS-FFL-154712.5 mm1"1.4~16$299.00 Ships in 2-3 weeks View
LS-FFL-157575 mm1/3"2.8~22$309.00 Ships in 2-3 weeks View
LS-FFL-15618 mm1/1.7"1:2.4-16$309.00 Ships in 2-3 weeks View
LS-FFL-156212 mm1/1.7"1:2.4-16$309.00 Ships in 2-3 weeks View
LS-FFL-15828 mm2/3"1:2.8~16$309.00 Ships in 2-3 weeks View
LS-FFL-158312 mm2/3"1:2.8~16$309.00 Ships in 2-3 weeks View
LS-FFL-156316 mm1/1.7"1:2.4-16$319.00 Ships in 2-3 weeks View
LS-FFL-158416 mm2/3"1:2.8~16$319.00 Ships in 2-3 weeks View
LS-FFL-154925 mm1"1.4~16$319.00 Ships in 2-3 weeks View
LS-FFL-1556f=16 mm1.1"$319.00 Ships in 2-3 weeks View
LS-FFL-1555f=12 mm1.1"$329.00 Ships in 2-3 weeks View
LS-FFL-156425 mm1/1.7"1:2.4-16$339.00 Ships in 2-3 weeks View
LS-FFL-158525 mm2/3"1:2.8~16$339.00 Ships in 2-3 weeks View
LS-FFL-154816 mm1"1.4~16$339.00 Ships in 2-3 weeks View
LS-FFL-155035 mm1"1.4~16$339.00 Ships in 2-3 weeks View
LS-FFL-156535 mm1/1.7"1:2.4-16$359.00 Ships in 2-3 weeks View
LS-FFL-1557f=25 mm1.1"$359.00 Ships in 2-3 weeks View
LS-FFL-1558f=35 mm1.1"$359.00 Ships in 2-3 weeks View
LS-FFL-155150 mm1"1.4~16$369.00 Ships in 2-3 weeks View
LS-FFL-1559f=50 mm1.1"$369.00 Ships in 2-3 weeks View
LS-FFL-1554f=8 mm1.1"$379.00 Ships in 2-3 weeks View
LS-FFL-156650 mm1/1.7"1:2.4-16$389.00 Ships in 2-3 weeks View
LS-FFL-158750 mm2/3"1:2.8~16$389.00 Ships in 2-3 weeks View
LS-FFL-155275 mm1"1.8~16$429.00 Ships in 2-3 weeks View
